Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 36
-
Groupset XT, XT Di2 -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano E8020, integrated -
Drivetrain 1 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Factory 36, Kashima coating
Rear Shock
FOX Float X2 Factory, 216x63mm
Drivetrain
Rear Derailleur
Shimano XT, Di2, Shadow Plus, 11-speed
Front Derailleur
None
Shift Levers
Shimano XT, Di2, M8050
Cassette
Shimano XT, 11-speed, 11-46 tooth
Crank
Shimano E8050
Chain
Shimano XT, 11-speed
Chain Guide
Shimano CDE80
Pedals
None
Wheels
Front Hub
Hope Pro 4
Rear Hub
Hope Pro 4
Rims
Stan's Flow Mk3, silver
Tires
Front: Maxxis Minion DHF WT 2.5", 3C, EXO, TR, Rear: Maxxis Minion DHR II WT 2.4", EXO, TR
Brakes
Brakes
Shimano Saint, 203mm rotors
Brake Levers
Shimano Saint
Cockpit
Stem
Hope, 35mm, black
Handlebar
Renthal FatBar, 800mm, 35mm diameter
Grips
Strange 130 Lock-on
Headset
Hope 49mm
Seat
Saddle
SDG Radar, cromo rail, black
Seatpost
FOX Factory Transfer 150mm, Kashima coating
Motor & Battery
Motor
Shimano E8000
Battery
Shimano E8020, integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.33 mm | 1.29 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Stack | 625.4 mm | 625.4 mm | 628.4 mm |
| Reach | 450.4 mm | 469.4 mm | 487.4 mm |
| Top Tube Length | 626.4 mm | 646.4 mm | 666.4 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406.4 mm | 431.8 mm | 457.2 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 120 mm | 120 mm | 125 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1217 mm | 1236 mm | 1257 mm |
| Bottom Bracket Drop | 13 mm | 13 mm | 13 mm |
| Standover Height | 744 mm | 751 mm | 764 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Alpine 6 E Factory is an Orange E Alpine model. 4 e-bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Fork
Orange Alpine 6 E Factory 2019 e-bike is equipped with the Fox Factory Float 36 fork, and has 170mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Orange Alpine 6 E Factory e-bike has the FOX Float X2 Factory model installed, and has a travel of 160mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Orange Alpine 6 E Factory 2019, has a 27.5″ aluminum model. These wheels will provide you with more control over the e-bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orange Alpine 6 E Factory has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
