Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 165mm -
Fork RockShox Lyrik Ultimate
-
Groupset X01 Eagle, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Lyrik Ultimate, 46mm offset, 110x15mm Boost thru-axle, Option: FOX 36 FLOAT Factory
Rear Shock
RockShox Super Deluxe Ultimate, 230mm x 65mm, Option: FOX X2 FLOAT Factory
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM Eagle XG1275, 12-speed, 10-50 tooth
Crank
Truvativ Descendant Carbon Eagle DUB
Bottom Bracket
SRAM DUB, 73mm
Chain
SRAM GX Eagle, 12-speed
Chain Guide
None, Option: MRP 1x
Pedals
None, Option: Burgtec MK4 Composite
Wheels
Front Hub
Hope Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
Hope Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear
Rims
e*thirteen TRS, 30mm internal width, Option: Stan's NoTubes Flow MK3
Tires
Front: Maxxis Minion DHF, 3C, EXO, TR, 27.5" x 2.5", Rear: Maxxis Minion DHR II, EXO, TR, 27.5" x 2.4"
Brakes
Brakes
Shimano XT Trail, 203mm front rotor, 180mm rear rotor, Option: Hope Tech 3 E4, 203mm front rotor, 180mm rear rotor
Brake Levers
Shimano XT Trail, Option: Hope Tech 3 E4
Cockpit
Stem
Hope, 35mm bore, 35mm length, Option: Burgtec, 35mm
Handlebar
Renthal Fatbar, 35mm bore, 800mm width, Option: Renthal Carbon Fatbar, 800mm width
Grips
Strange 130, single lock-on, black
Headset
Cane Creek, ZS49/28.6 upper, EC49/40 lower, for tapered steerer, Option: Hope Tech
Seat
Saddle
SDG Radar, steel rails, black/black
Seatpost
FOX Transfer Performance Elite dropper, 150mm drop, Option: FOX Transfer Factory dropper, 150mm or 170mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.39 mm | 1.33 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm | 337 mm |
| Stack | 600 mm | 618 mm | 618 mm | 622 mm | 627 mm |
| Reach | 430 mm | 445 mm | 465 mm | 484 mm | 503 mm |
| Top Tube Length | 603 mm | 623 mm | 643 mm | 663 mm | 683 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 432 mm | 457 mm | 483 mm | 508 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 120 mm | 120 mm | 125 mm | 130 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1206 mm | 1229 mm | 1249 mm | 1270 mm | 1291 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 18 mm | 18 mm |
| Standover Height | 698 mm | 722 mm | 750 mm | 773 mm | 788 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
Model Overview
Alpine 6 RS is part of the Orange Alpine model. Orange launched 24 bikes of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Alpine 6 RS components
Fork
The fork installed on this bike is the RockShox Lyrik Ultimate model. The travel on this model is 170mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Orange Alpine 6 RS bike has the RockShox Super Deluxe Ultimate model installed, and has a travel of 165mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the Alpine 6 RS bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orange Alpine 6 RS has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Dropper post
The Orange model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
