Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 165mm -
Fork Fox Factory Float 36
-
Groupset XTR -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 36 FLOAT Factory, 46mm offset, 110x15mm Boost thru-axle
Rear Shock
FOX X2 FLOAT Factory, 230mm x 65mm
Drivetrain
Rear Derailleur
Shimano XTR, 12-speed
Front Derailleur
N/A
Shift Levers
Shimano XTR, 12-speed
Cassette
Shimano XTR, 12-speed, 10-51 tooth
Crank
Shimano XTR
Bottom Bracket
Shimano HOLLOWTECH II, 73mm
Chain
Shimano XTR, 12-speed
Chain Guide
MRP 1x
Pedals
None, Option: Burgtec MK4 Composite
Wheels
Front Hub
DT Swiss 350, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
DT Swiss 350, 110x15mm Boost front, 148x12mm Boost rear
Rims
Stan's NoTubes Flow MK3
Tires
Front: Maxxis Minion DHF, 3C, EXO, TR, 27.5" x 2.5", Rear: Maxxis Minion DHR II, EXO, TR, 27.5" x 2.4"
Brakes
Brakes
Shimano XTR, 203mm front rotor, 180mm rear rotor
Brake Levers
Shimano XTR
Cockpit
Stem
Burgtec MK2 Enduro, 35mm clamp
Handlebar
Burgtec RideWide Carbon, 800mm width, 35mm bore
Grips
Strange 130, single lock-on, black
Headset
Hope Tech, ZS49/28.6 upper, EC49/40 lower for tapered steerer
Seat
Saddle
SDG Radar, CrMo rails, black/black
Seatpost
FOX Transfer Factory dropper, 150mm or 170mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.39 mm | 1.33 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm | 337 mm |
| Stack | 600 mm | 618 mm | 618 mm | 622 mm | 627 mm |
| Reach | 430 mm | 445 mm | 465 mm | 484 mm | 503 mm |
| Top Tube Length | 603 mm | 623 mm | 643 mm | 663 mm | 683 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 432 mm | 457 mm | 483 mm | 508 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 120 mm | 120 mm | 125 mm | 130 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1206 mm | 1229 mm | 1249 mm | 1270 mm | 1291 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 18 mm | 18 mm |
| Standover Height | 698 mm | 722 mm | 750 mm | 773 mm | 788 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
Model Overview
Alpine 6 XTR belongs to the Orange Alpine model. 24 bikes variations carry this model name so far. You can easily view all of the Orange Alpine bikes models from 2020, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro bikes average price
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Alpine 6 XTR components
Fork
This bike has the Fox Factory Float 36 fork installed. The fork’s travel is 170mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The Alpine 6 XTR has a rear shock with a travel of 165mm. The model FOX X2 FLOAT Factory is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The Alpine 6 XTR 2020 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Alpine 6 XTR comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
