Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 155mm -
Fork Öhlins RXF36
-
Groupset XT, Race Face -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Öhlins RXF 36 M.2 Air, TTX18 damper, 37mm offset
Rear Shock
Öhlins TTX1 Air, twin-tube damping, 230mm x 65mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Front Derailleur
None
Shift Levers
12-speed
Cassette
e*thirteen Helix R, 12-speed, 9-50 tooth
Crank
Race Face Aeffect
Bottom Bracket
Race Face, 73mm
Chain
KMC, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Hope Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rear Hub
Hope Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rims
Stan's NoTubes Flow MK4
Tires
Front: Maxxis Minion DHF, 3C, EXO+, 27.5" x 2.5", Rear: Maxxis Minion DHR II, EXO+, 27.5" x 2.4"
Brakes
Brakes
Shimano SLX Trail M7120, 4-piston, 203mm front rotor, 180mm rear rotor
Brake Levers
Shimano SLX Trail M7120
Cockpit
Stem
Burgtec Enduro, 42.5mm length
Handlebar
Burgtec RideWide Enduro, 800mm width
Grips
Strange Grappler, lock-on
Headset
Cane Creek, ZS49/28.6 upper, EC49/40 lower
Seat
Saddle
SDG Strange Bel-Air III
Seatpost
FOX Transfer Performance Elite dropper, 175mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.29 mm | 1.26 mm | 1.23 mm | 1.19 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm |
| Front Center | 792 mm | 814 mm | 835 mm | 856 mm |
| Rake | 37 mm | 37 mm | 35 mm | 36 mm |
| Trail | 140 mm | 140 mm | 142 mm | 141 mm |
| Stack | 587 mm | 596 mm | 605 mm | 609 mm |
| Reach | 456 mm | 474 mm | 493 mm | 511 mm |
| Top Tube Length | 603 mm | 623 mm | 643 mm | 663 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 381 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 63 ° | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 125 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1234 mm | 1256 mm | 1278 mm | 1299 mm |
| Bottom Bracket Drop | 17 mm | 17 mm | 17 mm | 17 mm |
| Standover Height | 718 mm | 740 mm | 770 mm | 793 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Alpine EVO SE is an Orange Alpine model. Orange released 24 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
The most economical model, the Orange Alpine 6 Pro-Line 2022 has a starting price of 7200$. Orange Alpine EVO SE 2022 on the other hand is the most expensive at 7600$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro bikes
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Orange Alpine EVO SE price was 7600$. Comparing the average cost of an Enduro bike to this one, you will see that Alpine EVO SE price is 111.17% more expensive.
Alpine EVO SE components
Fork
Orange Alpine EVO SE 2022 bike is equipped with the Öhlins RXF36 fork, and has 160mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this bike has the Öhlins TTX1 Air model, with a travel of 155mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When leaving the production line, the Alpine EVO SE model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Alpine EVO SE has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Orange Alpine EVO SE comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
