Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 145mm -
Fork RockShox 35 Silver
-
Groupset SX Eagle, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano STEPS E8035, integrated, removable -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox 35 Silver TK, 44mm offset
Rear Shock
RockShox Super Deluxe Select, 230mm x 57.5mm
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM SX Eagle, 12-speed, Single Click
Cassette
SRAM SX Eagle PG-1210, 12-speed, 11-50 tooth
Crank
Shimano M600, 165mm length
Chain
SRAM SX Eagle, 12-speed
Chain Guide
Shimano CDE80 upper slider
Pedals
None, Option: Burgtec Penthouse Flat MK5
Wheels
Front Hub
Strange Pro, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
Strange Pro, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
WTB ST Light i30, 30mm inner width
Tires
Maxxis Minion DHR II, EXO, TR, 27.5" x 2.4"
Brakes
Brakes
SRAM Guide RE, 4-piston, 200mm rotors
Brake Levers
SRAM Guide RE
Cockpit
Stem
Race Face Chester, 40mm length, 35mm bar clamp
Handlebar
Race Face Chester, 800mm width, 35mm clamp diameter
Grips
Strange Grappler, lock-on
Headset
Cane Creek, ZS49/28.6 upper, EC49/40 lower
Seat
Saddle
WTB Silverado Comp
Seatpost
SDG Tellis dropper, 150mm drop
Motor & Battery
Motor
Shimano STEPS EP8, 85Nm max torque, 250W
Battery
Shimano STEPS E8035, integrated, removable
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.31 mm | 1.28 mm | 1.26 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Stack | 614 mm | 614 mm | 623 mm | 632 mm |
| Reach | 419 mm | 468 mm | 486 mm | 503 mm |
| Top Tube Length | 626 mm | 646 mm | 666 mm | 686 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 406 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1223 mm | 1244 mm | 1266 mm | 1287 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 712 mm | 731 mm | 755 mm | 781 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Charger S completes the Orange E Charger model. There are 7 e-bikes that carry this model name. You can easily view all of the Orange E Charger e-bikes models from 2021, here.
Model range prices
Orange Charger S 2021 is the cheapest e-bike model and costs 5800$. Orange Charger Pro 2021 is the most expensive one and costs 6900$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5800$. If we compare this with the average Trail e-bike cost we notice that the price is 72.36% more expensive.
Overview of components
Fork
The RockShox 35 Silver is included from the factory. It has a travel distance of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The Charger S has a rear shock with a travel of 145mm. The model RockShox Super Deluxe Select is the one installed in this e-bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Orange Charger S 2021, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Charger S has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Charger S comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Orange model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
