Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon RL
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM NX, 11-speed
Front Derailleur
None
Shift Levers
SRAM NX, 11-speed
Cassette
SRAM NX, 11-42 tooth, 11-speed
Crank
SRAM NX, 24mm
Bottom Bracket
SRAM GXP
Chain
SRAM PC-1110
Chain Guide
None
Pedals
Kore Rivera Thermo
Wheels
Front Hub
Formula
Rear Hub
Formula
Rims
WTB ST Light i29
Tires
Front: Vittoria Goma 2.25", Rear: Vittoria Saguaro 2.2"
Brakes
Brakes
Front: Shimano MT400, 180mm rotor, Rear: Shimano MT400, 160mm rotor
Brake Levers
Shimano MT400
Cockpit
Stem
Strange Stalk
Handlebar
Strange, 0.5" rise, 750mm
Grips
Strange 130 Lock-on, black
Headset
FPD 44mm
Seat
Saddle
Kore Fazor
Seatpost
Strange, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.36 mm |
| Bottom Bracket Height | 312 mm | 312 mm | 312 mm |
| Stack | 642.8 mm | 642.8 mm | 651.8 mm |
| Reach | 442.8 mm | 462.8 mm | 480.8 mm |
| Top Tube Length | 627.8 mm | 647.8 mm | 667.8 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 431.8 mm | 457.2 mm | 508 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1187 mm | 1207 mm | 1227 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm |
| Standover Height | 684 mm | 703 mm | 742 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Clockwork EVO 29 Comp is part of the Orange Clockwork model. Orange released 14 bikes variations of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Clockwork EVO 29 Comp components
Fork
Orange Clockwork EVO 29 Comp 2019 bike is equipped with the RockShox Recon Silver RL fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on Clockwork EVO 29 Comp are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
