Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork RockShox 35 Silver
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Custom Butted OS Aluminium Tube. Wheel Size: 29.
Suspension Fork
RockShox 35 Silver TK 140mm 29
Drivetrain
Rear Derailleur
Shimano Deore 12spd
Shift Levers
Shimano Deore 12spd
Cassette
Sunrace CSMZ600 11-51t 12spd
Crank
Strange Prowheel MPX 170mm Narrow Wide 32t
Bottom Bracket
Shimano Hollow Tech II
Chain
KMC 12spd
Wheels
Rims
WTB ST i30 on Strange 29
Tires
Maxxis Minion DHF 2.5 3C Exo / DHR II 2.4 Exo 29
Brakes
Brakes
Clarks M2 180/180
Cockpit
Stem
Strange Stalk 40mm
Handlebar
Strange 1" Rise 780mm
Grips
Strange Grappler Lock-On
Headset
FPD 44mm / 56mm zerostack
Seat
Saddle
WTB Volt Steel
Seatpost
KS Ragei 150/170mm Drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm |
| Front Center | 791 mm | 1715 mm | 840 mm |
| Rake | 44 mm | 854 mm | 44 mm |
| Trail | 133 mm | -768 mm | 132 mm |
| Stack | 655 mm | 664 mm | 673 mm |
| Reach | 458 mm | 478 mm | 498 mm |
| Top Tube Length | 628 mm | 650 | 673 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 432 mm | 457 mm | 508 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1227 mm | 2152 mm | 1276 mm |
| Bottom Bracket Drop | 64 mm | 64 mm | 64 mm |
| Standover Height | 689 mm | 706 mm | 747 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Crush 29 comp is part of the Orange Crush model. Orange released 33 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Orange Crush 29 2023 is the cheapest bike model and costs 2436$. Orange Crush 29 comp 2023 is the most expensive one and costs 2859$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Orange released this model in 2023, its price was 2859$. Doing a quick comparison, we notice that Crush 29 comp price is 3.51% higher than the average cost of a Trail bike.
Overview of components
Fork
Orange Crush 29 comp 2023 bike is equipped with the RockShox 35 Silver fork, and has 140mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The wheels on Crush 29 comp are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Orange Crush 29 comp has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
