Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork RockShox Pike Ultimate
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Pike Ultimate, 51mm offset, 110x15mm Boost thru-axle, Option: FOX 36 FLOAT Factory
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM NX Eagle PG1230, 12-speed, 11-50 tooth
Crank
Truvativ Descendant 6k Eagle DUB
Bottom Bracket
SRAM DUB, 73mm
Chain
SRAM NX Eagle, 12-speed
Chain Guide
None, Option: MRP 1x
Pedals
None, Option: Burgtec MK4 Composite
Wheels
Front Hub
Hopt Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
Hopt Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear
Rims
e*thirteen TRS, 30mm internal width, Option: Stan's NoTubes Flow MK3
Tires
Front: Maxxis Minion DHF, 29" x 2.5" WT, Rear: Maxxis Minion DHR II, 29" x 2.4" WT
Brakes
Brakes
SRAM Guide RE, 200mm front rotor, 180mm rear rotor, Option: Shimano XT Trail, 203mm front rotor, 180mm rear rotor
Brake Levers
SRAM Guide RE, Option: Shimano XT Trail
Cockpit
Stem
Burgtec MK2 Enduro, 35mm
Handlebar
Burgtec RideWide Enduro, 800mm width
Grips
Strange 130, single lock-on, black
Headset
Cane Creek, ZS44/28.6 upper, EC44/40 lower, for tapered steerer, Option: Hope Tech
Seat
Saddle
SDG Radar, steel rails, black/black
Seatpost
FOX Transfer Performance Elite dropper, 150mm drop, Option: FOX Transfer Factory dropper, 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.48 mm | 1.44 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm |
| Stack | 646 mm | 655 mm | 664 mm |
| Reach | 426 mm | 443 mm | 460 mm |
| Top Tube Length | 618 mm | 638 mm | 658 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 432 mm | 457 mm | 508 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1193 mm | 1219 mm | 1240 mm |
| Bottom Bracket Drop | 64 mm | 64 mm | 64 mm |
| Standover Height | 687 mm | 704 mm | 744 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Crush 29 R completes the Orange Crush model. 27 bikes variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The Crush 29 R comes factory-installed with the RockShox Pike Ultimate fork. This has a travel range of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Crush 29 R are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Crush 29 R has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Crush 29 R comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
