Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork RockShox Lyrik Select
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Custom Butted OS Aluminium Tube. Wheel Size: MX - 29/27.5.
Suspension Fork
RockShox Lyrik Select 140mm 29
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM SX Eagle 12spd
Shift Levers
SRAM SX Eagle
Cassette
SRAM SX 1210 11-50T Eagle
Crank
SRAM SX Eagle 32t
Bottom Bracket
SRAM DUB
Chain
SRAM SX Eagle
Wheels
Rims
WTB ST i30 on Strange 29 +27
Tires
Maxxis Minion DHF 2.5 3c EXO 29/ DHR II 2.4 EXO 27.5
Brakes
Brakes
SRAM Guide T 200/180
Cockpit
Stem
Race Face Chester M35 x 40mm
Handlebar
RaceFace Chester 780mm M35
Grips
Strange Grappler Lock-On
Headset
FPD 44mm / 56mm zerostack
Seat
Saddle
WTB Volt SL
Seatpost
KS Ragei 150/170mm Drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.41 mm | 1.37 mm | 1.33 mm |
| Bottom Bracket Height | 432 mm | 432 mm | 432 mm | 432 mm |
| Front Center | 767 mm | 792 mm | 816 mm | 842 mm |
| Rake | -6 mm | -6 mm | -6 mm | -4 mm |
| Trail | 185 mm | 185 mm | 185 mm | 183 mm |
| Stack | 636 mm | 645 mm | 654 mm | 663 mm |
| Reach | 438 mm | 458 mm | 478 mm | 498 mm |
| Top Tube Length | 605 mm | 628 mm | 650 | 672 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1189 mm | 1214 mm | 1238 mm | 1264 mm |
| Bottom Bracket Drop | -58 mm | -58 mm | -58 mm | -58 mm |
| Standover Height | 648 mm | 657 mm | 666 mm | 677 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Crush MX Pro is an Orange Crush model. Orange released 33 bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Orange Crush Pro 2022 is the most affordable bike of this model and has a price of 3200$. On the other hand, Orange Crush MX Pro 2022, is the most expensive and costs 3389$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Orange released this model in 2022, its price was 3389$. If we compare this with the average Trail bike cost we notice that the price is 22.7% more expensive.
Crush MX Pro components
Fork
The Crush MX Pro comes factory-installed with the RockShox Lyrik Select fork. This has a travel range of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When leaving the production line, the Crush MX Pro model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Crush MX Pro has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Crush MX Pro comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Orange Crush MX Pro includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
