Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Fork RockShox Pike RCT3
-
Groupset X01 Eagle, GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Pike RCT3
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM Eagle XG-1275, 10-50 tooth, 12-speed
Crank
SRAM Descendant Carbon Eagle
Bottom Bracket
SRAM GXP
Chain
SRAM GX Eagle, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Hope Pro 4
Rear Hub
Hope Pro 4
Rims
Race Face Arc 30
Tires
Front: Maxxis Minion DHF 2.6", 3C, EXO, TR, Rear: Maxxis Rekon+ 2.6", EXO, TR
Brakes
Brakes
Front: SRAM Guide RE, 200mm rotor, Rear: SRAM Guide RE, 180mm rotor
Brake Levers
SRAM Guide RE
Cockpit
Stem
Renthal Apex, 50mm
Handlebar
Renthal Fatbar, 800mm, 35mm diameter
Grips
Strange 130 Lock-on
Headset
FPD 44mm
Seat
Saddle
SDG Radar, steel rails, black
Seatpost
RockShox Reverb 150mm with 1x remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.42 mm | 1.38 mm | 1.36 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Stack | 619.4 mm | 628.4 mm | 635.4 mm | 646.4 mm |
| Reach | 424.4 mm | 442.4 mm | 459.4 mm | 476.4 mm |
| Top Tube Length | 606.4 mm | 626.4 mm | 646.4 mm | 666.4 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 406.4 mm | 431.8 mm | 457.2 mm | 508 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1184 mm | 1206 mm | 1227 mm | 1249 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 658 mm | 681 mm | 711 mm | 746 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Crush RS is an Orange Crush model. There are 27 bikes that carry this model name. You can easily view all of the Orange Crush bikes models from 2019, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Enduro bikes average price
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The RockShox Pike RCT3 is included from the factory. It has a travel distance of 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on Crush RS are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Crush RS comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Orange Crush RS includes a dropper post. Therefore, climbing or descending will be a breeze.
