Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Factory Float 36
-
Groupset XT, Race Face -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX FLOAT 36 Factory, 37mm offset
Rear Shock
Cane Creek DB Air IL, 190mm x 45mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Front Derailleur
None
Shift Levers
12-speed
Cassette
e*thirteen Helix R, 12-speed, 9-50 tooth
Crank
Race Face Aeffect
Bottom Bracket
Race Face, 73mm
Chain
KMC, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Hope Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rear Hub
Hope Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rims
Stan's NoTubes Flow MK3
Tires
Front: Maxxis Minion DHF, 3C, EXO, 27.5" x 2.5", Rear: Maxxis Minion DHR II, EXO, 27.5" x 2.4"
Brakes
Brakes
Shimano SLX Trail M7120, 4-piston, 203mm front rotor, 180mm rear rotor
Brake Levers
Shimano SLX Trail M7120
Cockpit
Stem
Hope Tech, 35mm length, 35mm bar clamp
Handlebar
Renthal FatBar, 800mm width, 35mm clamp diameter
Grips
Strange Grappler, lock-on
Headset
Cane Creek, ZS49/28.6 upper, EC49/40 lower
Seat
Saddle
SDG Strange Bel-Air III
Seatpost
FOX Transfer Factory dropper, 175mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.32 mm | 1.3 mm | 1.24 mm | 1.24 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Front Center | 763 mm | 785 mm | 805 mm | 829 mm |
| Rake | 38 mm | 39 mm | 38 mm | 38 mm |
| Trail | 131 mm | 130 mm | 131 mm | 131 mm |
| Stack | 600 mm | 609 mm | 609 mm | 627 mm |
| Reach | 453 mm | 470 mm | 491 mm | 506 mm |
| Top Tube Length | 601 mm | 621 mm | 641 mm | 661 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 406 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 110 mm | 130 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1202 mm | 1224 mm | 1244 mm | 1268 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 698 mm | 718 mm | 736 mm | 763 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Five EVO SE is part of the Orange Five model. 23 bikes variations carry this model name so far. You can easily view all of the Orange Five bikes models from 2022, here.
Model range prices
The most economical model, the Orange Five EVO Pro-Line 2022 has a starting price of 6800$. Orange Five EVO SE 2022 on the other hand is the most expensive at 7400$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Orange Five EVO SE price was 7400$. Doing a quick comparison, we notice that Five EVO SE price is 167.92% higher than the average cost of a Trail bike.
Five EVO SE components
Fork
Orange Five EVO SE 2022 bike is equipped with the Fox Factory Float 36 fork, and has 130mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Five EVO SE has a rear shock with a travel of 120mm. The model Cane Creek DB Air IL is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The Five EVO SE 2022 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orange Five EVO SE is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Orange Five EVO SE bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Orange Five EVO SE comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
