Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 140mm -
Fork Fox Factory Float 36
-
Groupset X01 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Factory 36 Float
Rear Shock
FOX Float DPX2 Factory, 190mm x 50mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle, 12-speed
Cassette
SRAM CS XG-1295 Eagle, 10 x 50 tooth, 12-speed
Crank
SRAM X01 Carbon Eagle
Bottom Bracket
73mm
Chain
SRAM X01 Eagle, silver
Chain Guide
None included
Pedals
None included
Wheels
Front Hub
Hope Pro 4, black
Rear Hub
Hope Pro 4, black
Rims
Race Face Arc 30, grey
Tires
Front: Maxxis High Roller II 3c Exo TR, 2.4", Rear: Maxxis High Roller II Exo TR 2, 2.3"
Brakes
Brakes
Hope Tech 3 E4, black with 203mm front/180mm rear rotors
Brake Levers
Hope Tech 3 E4
Cockpit
Stem
Race Face Turbine R, 50mm length, 35mm clamp
Handlebar
Race Face Next R, carbon, stealth, 800mm width
Grips
Strange 130, single lock-on, black
Headset
Hope, 49mm, black
Seat
Saddle
SDG Fly MTN, chromoly rail, black/orange
Seatpost
FOX Factory Transfer, 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.44 mm | 1.38 mm | 1.37 mm | 1.34 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm | 333 mm |
| Stack | 597 mm | 606 mm | 606 mm | 624 mm | 633 mm |
| Reach | 402 mm | 420 mm | 440 mm | 455 mm | 472 mm |
| Top Tube Length | 573 mm | 593 mm | 613 mm | 633 mm | 653 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 406.4 mm | 431.8 mm | 457.2 mm | 508 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 110 mm | 130 mm | 140 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1132 mm | 1154 mm | 1174 mm | 1197 mm | 1218 mm |
| Bottom Bracket Drop | 22 mm | 22 mm | 22 mm | 22 mm | 22 mm |
| Standover Height | 689 mm | 713 mm | 718 mm | 738 mm | 788 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Five Factory is part of the Orange Five model. Orange released 23 bikes variations of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
This bike has the Fox Factory Float 36 fork installed. The fork’s travel is 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the FOX Float DPX2 Factory model, with a travel of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Orange Five Factory 2018, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Five Factory has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
