Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Revelation RC
-
Groupset SLX, Race Face -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Revelation RC
Rear Shock
RockShox Monarch DB RT, 190mm x 51mm
Drivetrain
Rear Derailleur
Shimano SLX Shadow Plus
Front Derailleur
N/A
Shift Levers
Shimano SLX, 11-speed
Cassette
SRAM PC-1130, 11 x 42, 11-speed
Crank
Race Face Aeffect, direct mount
Bottom Bracket
Race Face, 73mm
Chain
SRAM PC1110
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
JoyTech, Boost rear
Rear Hub
JoyTech, Boost rear
Rims
Kore Realm 3.0, 32 hole
Tires
Maxxis High Roller II EXO TR, 2.3"
Brakes
Brakes
Shimano MT500 with 180mm rotors
Brake Levers
Shimano MT500
Cockpit
Stem
Kore Cubix, 50mm length, 35mm clamp
Handlebar
Kore Durox, 780mm width
Grips
Strange 130, single lock-on, black
Headset
Cane Creek, 49mm
Seat
Saddle
Kore Conex
Seatpost
Kore Dropper, 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.44 mm | 1.38 mm | 1.37 mm | 1.34 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm | 333 mm |
| Stack | 597 mm | 606 mm | 606 mm | 624 mm | 633 mm |
| Reach | 402 mm | 420 mm | 440 mm | 455 mm | 472 mm |
| Top Tube Length | 573 mm | 593 mm | 613 mm | 633 mm | 653 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 406.4 mm | 431.8 mm | 457.2 mm | 508 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 110 mm | 130 mm | 140 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1132 mm | 1154 mm | 1174 mm | 1197 mm | 1218 mm |
| Bottom Bracket Drop | 22 mm | 22 mm | 22 mm | 22 mm | 22 mm |
| Standover Height | 689 mm | 713 mm | 718 mm | 738 mm | 788 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Five S is part of the Orange Five model. 23 bikes variations carry this model name so far. Take a sneak peek at all Orange Five bikes models from 2018, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The RockShox Revelation RC is included from the factory. It has a travel distance of 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the RockShox Monarch DB RT model, with a travel of 140mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The Five S 2018 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the Five S. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
