Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Revelation RC
-
Groupset SLX, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Revelation RC
Rear Shock
RockShox Monarch DB RT, 184x44mm
Drivetrain
Rear Derailleur
Shimano SLX Shadow Plus, 11-speed
Front Derailleur
None
Shift Levers
Shimano SLX, 11-speed
Cassette
SunRace CSM8, 11-speed, 11-46 tooth
Crank
Race Face Ride Cinch
Bottom Bracket
Race Face
Chain
SRAM PC-1110
Chain Guide
None
Pedals
None
Wheels
Front Hub
Joytech
Rear Hub
Joytech
Rims
Kore Realm 3.0
Tires
Maxxis High Roller II 2.3", EXO, TR
Brakes
Brakes
Shimano MT500, 180mm rotors
Brake Levers
Shimano MT500
Cockpit
Stem
Kore Cubix, 50mm
Handlebar
Kore Durox, 35mm diameter, 780mm
Grips
Strange 130 Lock-on
Headset
Cane Creek 49mm
Seat
Saddle
Kore Conex
Seatpost
Kore Dropper, 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.37 mm | 1.31 mm | 1.3 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Stack | 586 mm | 596 mm | 596 mm | 614 mm |
| Reach | 419 mm | 436 mm | 456 mm | 471 mm |
| Top Tube Length | 588 mm | 608 mm | 628 mm | 648 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 431.8 mm | 475.2 mm | 508 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 110 mm | 130 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1130 mm | 1151 mm | 1171 mm | 1194 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 688 mm | 728 mm | 742 mm | 781 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Four S is part of the Orange Four model. 10 bikes variations carry this model name so far. Take a sneak peek at all Orange Four bikes models from 2019, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
The RockShox Revelation RC is included from the factory. It has a travel distance of 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is RockShox Monarch DB RT, with a travel distance of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Four S model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orange Four S has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Orange Four S bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Orange Four S comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
