Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Fork RockShox Lyrik Ultimate
-
Groupset GX Eagle AXS, XT -
Suspension Hardtail -
Motor Shimano mid-drive -
Battery Shimano E806 630wh Integrated battery Gen 2 -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Monocoque UK Formed Custom Aluminium Tubing. Wheel Size: MX - 29/27.5.
Suspension Fork
RockShox Lyrik Ultimate 150mm 29
Drivetrain
Rear Derailleur
SRAM GX AXS Eagle 12spd
Shift Levers
SRAM GX AXS Eagle
Cassette
SRAM XG 1275 10-52t Eagle
Crank
Shimano XT 165 E 34t
Bottom Bracket
Shimano EP8 DU Integrated
Chain
SRAM NX Eagle
Wheels
Rims
Stans Flow Mk4 + Hope Pro 4 (Black) 29 + 27
Tires
Maxxis Minion DHF 2.5 3c EXO+ 29 / DHR II 2.4 3c EXO+ 27.5
Brakes
Brakes
SRAM Guide RE 200/200
Cockpit
Stem
Burgtec Enduro Black 42.5mm
Handlebar
Burgtec RideWide Enduro 800mm
Grips
Strange Grappler Lock-On
Headset
FPD 44mm / 56mm zerostack
Seat
Saddle
SDG Strange Bel Air III
Seatpost
Rockshox Reverb AXS 170mm
Motor & Battery
Motor
Shimano EP801
Battery
Shimano E806 630wh Integrated battery Gen 2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.552 mm | 1.484 mm | 1.446 mm | 1.411 mm |
| Bottom Bracket Height | 297 mm | 297 mm | 297 mm | 297 mm |
| Front Center | 784 mm | 804 mm | 826 mm | 848 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 128 mm | 128 mm | 128 mm | 128 mm |
| Stack | 675 mm | 675 mm | 684 mm | 693 mm |
| Reach | 435 mm | 455 mm | 473 mm | 491 mm |
| Top Tube Length | 610 mm | 630 mm | 650 | 670 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 406 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 130 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1204 mm | 1224 mm | 1246 mm | 1268 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 675 mm | 720 mm | 730 mm | 743 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
MsIsle AXS belongs to the Orange E Msisle model. Orange released 2 e-bikes variations of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Orange MsIsle Pro 2024 is the cheapest e-bike model and costs 7730$. Orange MsIsle AXS 2024 is the most expensive one and costs 10166$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 10166$. If we compare this with the average Enduro e-bike cost we notice that the price is 112.46% more expensive.
MsIsle AXS components
Fork
This e-bike has the RockShox Lyrik Ultimate fork installed. The fork’s travel is 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on MsIsle AXS are the 27.5″ aluminum type. These wheels will provide you with more control over the e-bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orange MsIsle AXS has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the MsIsle AXS. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
