Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 140mm -
Fork Fox Performance Float 34
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly
Suspension Fork
FOX FLOAT 34 Performance, 46mm offset
Rear Shock
None
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM SX Eagle PG-1210, 12-speed, 11-50 tooth
Crank
SRAM SX Eagle DUB
Bottom Bracket
SRAM DUB, 73mm
Chain
SRAM SX Eagle, 12-speed
Chain Guide
None
Pedals
None, Option: Burgtec Penthouse Flat MK5
Wheels
Front Hub
Strange, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
Strange, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
WTB ST Light i30, 30mm internal width
Tires
Front: WTB Vigilante, 29" x 2.5", Rear: WTB Trail Boss, 29" x 2.4"
Brakes
Brakes
Shimano MT401, 2-piston, 180mm front rotor, 160mm rear rotor
Brake Levers
Shimano MT401
Cockpit
Stem
Race Face Chester, 40mm length, 35mm bar clamp
Handlebar
Race Face Chester, 780mm width, 35mm clamp diameter
Grips
Strange Grappler, lock-on
Headset
FPD, ZS44/28.6 upper, EC44/40 lower
Seat
Saddle
WTB Silverado Sport
Seatpost
KS Rage-i dropper, 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.43 mm | 1.36 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 302 mm |
| Stack | 644 mm | 653 mm | 662 mm |
| Reach | 435 mm | 458 mm | 485 mm |
| Top Tube Length | 620 mm | 647 mm | 676 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1200 mm | 1228 mm | 1259 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm |
| Standover Height | 690 mm | 708 mm | 749 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
P7 29 S is part of the Orange P7 model. 18 bikes variations carry this model name so far. Take a sneak peek at all Orange P7 bikes models from 2021, by clicking here.
Model range prices
Orange P7 29 S 2021 is the most economical model, with a starting price of 2600$. Orange P7 R 2021 on the other hand costs 3700$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2021 for 2600$. Comparing the average cost of a Trail bike to this one, you will see that P7 29 S price is 6.23% smaller.
Overview of components
Fork
The fork installed on this bike is the Fox Performance Float 34 model. The travel on this model is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on P7 29 S are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orange P7 29 S is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
P7 29 S comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Orange P7 29 S comes with a dropper post. Therefore, climbing or descending will be a breeze.
