Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 27.5" -
Travel Front 150mm -
Fork RockShox Revelation RC
-
Groupset SLX, Race Face -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly
Suspension Fork
RockShox Revelation RC
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano SLX Shadow Plus, 11-speed
Front Derailleur
None
Shift Levers
Shimano SLX, 11-speed
Cassette
SunRace CSM8, 11-speed, 11-46 tooth
Crank
Race Face Ride Cinch
Bottom Bracket
Race Face
Chain
SRAM PC-1110
Chain Guide
None
Pedals
Kore Rivera Thermo
Wheels
Front Hub
Formula
Rear Hub
Formula
Rims
Kore Realm 3.0
Tires
Front: WTB Vigilante 2.6", Rear: WTB Trail Boss 2.6"
Brakes
Brakes
Shimano MT500, 180mm rotors
Brake Levers
Shimano MT500
Cockpit
Stem
Kore Cubix, 50mm
Handlebar
Kore Durox, 35mm diameter, 780mm
Grips
Strange 130 Lock-on, black
Headset
FPD 44mm
Seat
Saddle
Kore Conex
Seatpost
Kore Dropper, 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.43 mm | 1.4 mm | 1.36 mm |
| Bottom Bracket Height | 301 mm | 301 mm | 301 mm | 301 mm |
| Stack | 625.4 mm | 636.4 mm | 646.4 mm | 652.4 mm |
| Reach | 428.4 mm | 446.4 mm | 462.4 mm | 481.4 mm |
| Top Tube Length | 606.4 mm | 626.4 mm | 646.4 mm | 666.4 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406.4 mm | 431.8 mm | 457.2 mm | 508 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 657 mm | 692 mm | 706 mm | 746 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
P7 S belongs to the Orange P7 model. 18 bikes variations carry this model name so far. You can easily view all of the Orange P7 bikes models from 2019, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The RockShox Revelation RC is included from the factory. It has a travel distance of 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the P7 S model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orange P7 S has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Orange model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
