Orange Phase MX AXS 2023
2023 E-bike
Estimate price |
12,564$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 165mm -
Fork Fox Factory Float 38
-
Groupset GX Eagle AXS, XT -
Suspension Full -
Motor Shimano mid-drive -
Battery Shimano E806 630wh Integrated battery Gen 2 -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Monocoque UK Formed Custom Aluminium Tubing. Wheel Size: MX - 29/27.5. Rear wheel travel: 165.
Suspension Fork
Fox Factory 38 Float 170mm 29
Rear Shock
Fox Float X2 Factory 230x65
Drivetrain
Rear Derailleur
SRAM GX AXS Eagle 12spd
Shift Levers
SRAM GX AXS Eagle
Cassette
SRAM XG 1275 10-52t Eagle
Crank
Shimano XT 165 E 34t
Bottom Bracket
Shimano EP8 DU Integrated
Chain
SRAM NX Eagle
Wheels
Rims
E13 TRS 30mm (Grey) + Hope Pro 4 (Black) 29 + 27.5
Tires
Maxxis Minion DHF 2.5 3c EXO+ 29 / DHR II 2.4 3c EXO+ 27.5
Brakes
Brakes
SRAM Guide RE 200/200
Cockpit
Stem
Burgtec Enduro Black 42.5mm
Handlebar
Burgtec RideWide Enduro 800mm
Grips
Strange 130 Single Lock-On Black
Headset
Acros 49mm Blocklock for Tapered Steerer
Seat
Saddle
SDG Strange Bel Air III
Seatpost
Rockshox Reverb AXS 170mm
Motor & Battery
Motor
Shimano EP801
Battery
Shimano E806 630wh Integrated battery Gen 2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.35 mm | 1.32 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm |
| Front Center | 818 mm | 838 mm | 860 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 130 mm | 130 mm | 129 mm |
| Stack | 647 mm | 647 mm | 656 mm |
| Reach | 461 mm | 481 mm | 498 mm |
| Top Tube Length | 637 mm | 645 mm | 660 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1253 mm | 1273 mm | 1295 mm |
| Bottom Bracket Drop | 31 mm | 31 mm | 31 mm |
| Standover Height | 736 mm | 758 mm | 781 mm |
| Rear Travel | 165 mm | 165 mm | 165 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Phase MX AXS is part of the Orange E Phase model. There are 23 e-bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Orange Phase S 2023 is the most economical model, with a starting price of 8471$. Orange Phase 29 AXS 2023 on the other hand costs 11436$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro e-bikes average price
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
When Orange released this model in 2023, its price was 11436$. Comparing the average cost of an Enduro e-bike to this one, you will see that Phase MX AXS price is 139% higher.
Overview of components
Fork
The Phase MX AXS comes factory-installed with the Fox Factory Float 38 fork. This has a travel range of 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this e-bike has the Fox Float X2 Factory 230×65 model, with a travel of 165mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on Phase MX AXS are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Phase MX AXS has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Orange Phase MX AXS e-bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
The Orange model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
