Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 135mm -
Fork Fox Factory Float 36
-
Groupset XTR -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Factory 36 Float
Rear Shock
FOX Float DPX2 Factory, 200x51mm
Drivetrain
Rear Derailleur
Shimano XTR, 12-speed
Front Derailleur
None
Shift Levers
Shimano XTR, 12-speed
Cassette
Shimano XTR, 12-speed, 10-51 tooth
Crank
Shimano XTR
Bottom Bracket
Shimano Hollow Tech II
Chain
Shimano XTR
Chain Guide
None
Pedals
None
Wheels
Front Hub
Shimano XTR
Rear Hub
Shimano XTR
Rims
Stans Flow Mk3
Tires
Front: Maxxis Minion DHF 2.3", 3C, EXO, TR, Rear: Maxxis High Roller II 2.3", EXO, TR
Brakes
Brakes
Front: Shimano XTR, 203mm rotor, Rear: Shimano XTR, 180mm rotor
Brake Levers
Shimano XTR
Cockpit
Stem
Burgtec MK2 Enduro, black, 50mm
Handlebar
Burgtec RideWide Carbon, 800mm, 35mm diameter
Grips
Strange 130 Lock-on
Headset
Hope 49mm
Seat
Saddle
SDG Radar, cromo rail, black
Seatpost
FOX Factory Transfer 150mm, Kashima coating
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.4 mm | 1.37 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Stack | 621.8 mm | 630.8 mm | 639.8 mm |
| Reach | 433.8 mm | 450.8 mm | 467.8 mm |
| Top Tube Length | 612.8 mm | 632.8 mm | 652.8 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 431.8 mm | 475.2 mm | 508 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1180 mm | 1201 mm | 1222 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm |
| Standover Height | 717 mm | 739 mm | 792 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Stage 5 XTR belongs to the Orange Stage model. There are 43 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
This bike has the Fox Factory Float 36 fork installed. The fork’s travel is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the FOX Float DPX2 Factory rear shock model, which has a travel of 135mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Orange Stage 5 XTR 2019, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orange Stage 5 XTR is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Orange Stage 5 XTR includes a dropper post. Therefore, climbing or descending will be a breeze.
