Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 135mm -
Fork Fox Factory Float 36
-
Groupset XTR -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 36 FLOAT Factory, 42mm offset, 110x15mm Boost thru-axle
Rear Shock
FOX DPX2 FLOAT Factory, 210mm x 50mm
Drivetrain
Rear Derailleur
Shimano XTR, 12-speed
Front Derailleur
N/A
Shift Levers
Shimano XTR, 12-speed
Cassette
Shimano XTR, 12-speed, 10-51 tooth
Crank
Shimano XTR
Bottom Bracket
Shimano HOLLOWTECH II, 73mm
Chain
Shimano XTR, 12-speed
Chain Guide
MRP 1x
Pedals
None, Option: Burgtec MK4 Composite
Wheels
Front Hub
DT Swiss 350, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
DT Swiss 350, 110x15mm Boost front, 148x12mm Boost rear
Rims
Stan's NoTubes Flow MK3
Tires
Front: Maxxis Minion DHF, 29" x 2.5" WT, Rear: Maxxis Minion DHR II, 29" x 2.4" WT
Brakes
Brakes
Shimano XTR, 203mm front rotor, 180mm rear rotor
Brake Levers
Shimano XTR
Cockpit
Stem
Burgtec MK2 Enduro, 35mm
Handlebar
Burgtec RideWide Carbon, 800mm width
Grips
Strange 130, single lock-on, black
Headset
Hope Tech, ZS49/28.6 upper, EC49/40 lower for tapered steerer
Seat
Saddle
SDG Radar, CrMo rails, black/black
Seatpost
FOX Transfer Factory dropper, 150mm or 170mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.32 mm | 1.29 mm |
| Bottom Bracket Height | 325 mm | 325 mm | 325 mm |
| Stack | 624 mm | 633 mm | 642 mm |
| Reach | 461 mm | 479 mm | 497 mm |
| Top Tube Length | 618 mm | 638 mm | 658 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 459 mm | 459 mm | 459 mm |
| Wheelbase | 1240 mm | 1262 mm | 1284 mm |
| Bottom Bracket Drop | 49 mm | 49 mm | 49 mm |
| Standover Height | 718 mm | 740 mm | 793 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Stage 5 XTR is part of the Orange Stage model. Orange released 43 bikes variations of this model so far. Take a sneak peek at all Orange Stage bikes models from 2020, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Stage 5 XTR components
Fork
The Fox Factory Float 36 is included from the factory. It has a travel distance of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is FOX DPX2 FLOAT Factory, with a travel distance of 135mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Stage 5 XTR model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orange Stage 5 XTR is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Stage 5 XTR comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
