Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Lyrik Ultimate
-
Groupset GX Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Monocoque UK Formed Custom Aluminium Tubing. Wheel Size: 29. Rear wheel travel: 140.
Suspension Fork
RockShox Lyrik Ultimate 150mm 29
Rear Shock
RockShox Super Deluxe Ultimate 210x55
Drivetrain
Rear Derailleur
SRAM GX AXS Eagle 12spd
Shift Levers
SRAM GX AXS Eagle
Cassette
SRAM XG 1275 10-52t Eagle
Crank
SRAM GX Eagle 32t
Bottom Bracket
SRAM DUB
Chain
SRAM NX Eagle
Wheels
Rims
E13 LG1 EN 30mm (Grey) + Hope Pro 4 (Black) 29
Tires
Maxxis Minion DHF 2.5 3C Exo / DHR II 2.4 Exo 29
Brakes
Brakes
SRAM Guide RE 200/180
Cockpit
Stem
Burgtec Enduro Black 42.5mm
Handlebar
Burgtec RideWide Enduro 800mm
Grips
Strange Grappler Lock-On
Headset
Cane Creek 49mm for Tapered Steerer
Seat
Saddle
SDG Strange Bel Air III
Seatpost
Rockshox Reverb AXS 170mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.29 mm | 1.27 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm |
| Front Center | 808 mm | 827 mm | 849 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 129 mm | 129 mm | 130 mm |
| Stack | 628 mm | 628 mm | 638 mm |
| Reach | 466 mm | 485 mm | 503 mm |
| Top Tube Length | 623 mm | 643 mm | 663 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1270 mm | 1289 mm | 1311 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm |
| Standover Height | 731 mm | 742 mm | 795 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Stage 6 Evo AXS completes the Orange Stage model. 51 bikes variations carry this model name so far. You can easily view all of the Orange Stage bikes models from 2023, here.
Model range prices
Orange Stage Evo Pro 2023 is the most affordable bike of this model and has a price of 5506$. On the other hand, Orange Stage 6 Evo AXS 2023, is the most expensive and costs 8789$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Orange released this model in 2023, its price was 8789$. In conclusion, this bike price is 218.21% more expensive than the price of the average Trail bike.
Stage 6 Evo AXS components
Fork
Orange Stage 6 Evo AXS 2023 bike is equipped with the RockShox Lyrik Ultimate fork, and has 150mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the RockShox Super Deluxe Ultimate 210×55 model, with a travel of 140mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Orange Stage 6 Evo AXS 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Stage 6 Evo AXS comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Orange Stage 6 Evo AXS includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
