Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Factory Float 36
-
Groupset X01 Eagle, Truvativ Descendant Carbon -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Factory 36, black or orange
Rear Shock
FOX Float X2 Factory, 200mm x 57mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle, 12-speed
Cassette
SRAM CS XG 1295 Eagle, 10-50 tooth, 12-speed
Crank
Descendant Carbon Eagle
Bottom Bracket
SRAM GXP Team
Chain
SRAM X01 Eagle, silver
Chain Guide
Not included
Pedals
None included
Wheels
Front Hub
Hope Pro 4, black, Boost rear
Rear Hub
Hope Pro 4, black, Boost rear
Rims
Race Face Arc 30, grey
Tires
Front: Maxxis Minion DHF, 2.5" 3c EXO TR, Rear: Maxxis Minion DHR II, 2.4" EXO T
Brakes
Brakes
Hope Tech 3 E4 with 203mm front/180mm rear rotors, black or orange
Brake Levers
Hope Tech 3 E4
Cockpit
Stem
Race Face Turbine R, 32mm or Burgtec Mk2 Enduro, 35mm, black
Handlebar
Race Face Next R Carbon Stealth, 800mm width or Burgtec RideWide, carbon, 800mm width
Grips
Strange 130 Lock-on, black or orange
Headset
Hope, 49mm, black or orange
Seat
Saddle
SDG Fly MTN, cromo rail, black/grey
Seatpost
FOX Factory Transfer, 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.39 mm | 1.36 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Stack | 630.8 mm | 640.8 mm | 649.8 mm |
| Reach | 441.8 mm | 459.8 mm | 476.8 mm |
| Top Tube Length | 617.8 mm | 637.8 mm | 657.8 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 431.8 mm | 457.2 mm | 508 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1220 mm | 1242 mm | 1263 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm |
| Standover Height | 730 mm | 741 mm | 794 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Stage 6 Factory is part of the Orange Stage model. There are 43 bikes that carry this model name. Check out the entire range from 2018 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
This bike has the Fox Factory Float 36 fork installed. The fork’s travel is 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the FOX Float X2 Factory model, with a travel of 150mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The Stage 6 Factory 2018 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Stage 6 Factory comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Stage 6 Factory comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Orange Stage 6 Factory includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
