Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Factory Float 36
-
Groupset XT, Shimano -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano STEPS E8035, integrated -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 36 FLOAT Factory, 42mm offset
Rear Shock
FOX DPX2 FLOAT Factory, 230mm x 57.5mm
Drivetrain
Rear Derailleur
Shimano XT, 12-speed
Front Derailleur
N/A
Shift Levers
Shimano XT, 12-speed
Cassette
Shimano XT, 12-speed, 10-51 tooth
Crank
Shimano E8050
Chain
Shimano XT, 12-speed
Chain Guide
MRP 1x E-Bike
Pedals
None, Option: Burgtec MK4 Composite
Wheels
Front Hub
DT Swiss 350, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
DT Swiss 350, 110x15mm Boost front, 148x12mm Boost rear
Rims
Stan's NoTubes Flow MK3
Tires
Front: Maxxis Minion DHF, 3C, EXO+, 29" x 2.5", Rear: Maxxis Minion DHR II, 3C, EXO+, 29" x 2.4"
Brakes
Brakes
Shimano XT Trail, 203mm rotors, Option: Hope Tech 3 E4, 203mm rotors
Brake Levers
Shimano XT Trail, Option: Hope Tech 3 E4,
Cockpit
Stem
Hope Tech, 35mm clamp, 35mm length
Handlebar
Renthal Fatbar, 800mm width, 35mm bore
Grips
Strange 130, single lock-on, black
Headset
Hope Tech, ZS49/28.6 upper, EC49/40 lower, for tapered steerer
Seat
Saddle
SDG Radar, steel rails, black/black
Seatpost
FOX Transfer Factory dropper, 150mm or 170mm drop
Motor & Battery
Motor
Shimano STEPS E8000, 70Nm max torque
Battery
Shimano STEPS E8035, integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.29 mm | 1.26 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm |
| Stack | 628 mm | 628 mm | 636 mm |
| Reach | 465 mm | 486 mm | 503 mm |
| Top Tube Length | 623 mm | 643 mm | 663 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1264 mm | 1284 mm | 1306 mm |
| Bottom Bracket Drop | 31 mm | 31 mm | 31 mm |
| Standover Height | 722 mm | 750 mm | 773 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Surge 29 Factory completes the Orange E Surge model. 18 e-bikes variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Surge 29 Factory components
Fork
This e-bike has the Fox Factory Float 36 fork installed. The fork’s travel is 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this e-bike is FOX DPX2 FLOAT Factory, with a travel distance of 150mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The Surge 29 Factory 2020 e-bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orange Surge 29 Factory is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Surge 29 Factory comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
The Orange model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
