Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 160mm -
Fork Fox Factory Float 36
-
Groupset XT, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Monocoque UK Formed Custom Aluminium Tubing. Wheel Size: MX - 29/27.5. Rear wheel travel: 160.
Suspension Fork
Fox Factory 36 Float 160mm 29 (black)
Rear Shock
Fox Float X2 Factory 205x65
Drivetrain
Rear Derailleur
Shimano XT 12spd
Shift Levers
Shimano XT 12spd
Cassette
Shimano XT 10-51T 12spd
Crank
SRAM GX Eagle 32t
Bottom Bracket
SRAM DUB
Chain
SRAM NX Eagle
Wheels
Rims
Stans Flow Mk4 + Hope Pro 5 (Black) 29 + 27
Tires
Maxxis Minion DHF 2.5 3c EXO 29/ DHR II 2.4 EXO 27.5
Brakes
Brakes
Shimano XT Trail 203/180
Cockpit
Stem
Burgtec Enduro Black 42.5mm
Handlebar
Renthal FatBar M35 800mm
Grips
Strange Grappler Lock-On
Headset
FPD 49mm / 56mm zerostack
Seat
Saddle
SDG Strange Bel Air III
Seatpost
Fox Factory Transfer 150/175mm Drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.406 mm | 1.346 mm | 1.315 mm | 1.286 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 786 mm | 806 mm | 828 mm | 850 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 133 mm | 133 mm | 133 mm | 134 mm |
| Stack | 630 mm | 630 mm | 639 mm | 648 mm |
| Reach | 448 mm | 468 mm | 486 mm | 504 mm |
| Top Tube Length | 605 mm | 625 mm | 645 mm | 665 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 381 mm | 406 mm | 432 mm | 457 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1235 mm | 1255 mm | 1277 mm | 1299 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 716 mm | 733 mm | 744 mm | 797 mm |
| Rear Travel | 160 mm | 160 mm | 160 mm | 160 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Switch 6 Factory is an Orange Switch model. There are 16 bikes that carry this model name. You can easily view all of the Orange Switch bikes models from 2024, here.
Model range prices
Orange Switch Pro 2024 is the cheapest bike model and costs 4659$. Orange Switch 6 Factory 2024 is the most expensive one and costs 7624$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro bikes average price
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 7624$. In conclusion, this bike price is 111.84% more expensive than the price of the average Enduro bike.
Overview of components
Fork
Orange Switch 6 Factory 2024 bike is equipped with the Fox Factory Float 36 fork, and has 160mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The Switch 6 Factory has a rear shock with a travel of 160mm. The model Fox Float X2 Factory 205×65 is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Orange Switch 6 Factory 2024, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orange Switch 6 Factory is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Orange Switch 6 Factory comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
