Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox Judy Silver TK
-
Groupset NX Eagle, Truvativ Stylo -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Alma Hydro Boost141 Triple Butted 4X4 Taper PF Race
Suspension Fork
RockShox Judy Silver TK Remote Solo Air 100 QR15x110 Boost
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM NX PG-1230 Eagle 11-50t 12-Speed
Crank
SRAM Stylo 6K Eagle Dub Boost 32t
Chain
SRAM NX Eagle 12-Speed
Wheels
Rims
Mach1 Klixx 23c Tubeless Ready
Tires
Maxxis Ikon 2.20" FB 60 TPI Dual
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
Alloy 31.8mm interface 7º
Handlebar
Alloy Flat 31.8mm 720mm
Headset
FSA 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Royal Seta Sport
Seatpost
Alloy forge head 27.2 Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.529 mm | 1.443 mm |
| Bottom Bracket Height | 312 mm | 312 mm |
| Front Center | 624 mm | 657 mm |
| Rake | 44 mm | 44 mm |
| Trail | 101 mm | 100 mm |
| Stack | 581 mm | 590 mm |
| Reach | 380 mm | 409 mm |
| Top Tube Length | 550 mm | 582 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 445 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 105 mm | 115 mm |
| Chainstay Length | 425 mm | 425 mm |
| Wheelbase | 1045 mm | 1078 mm |
| Bottom Bracket Drop | 43 mm | 43 mm |
| Standover Height | 716 mm | 735 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 155 cm | 165 cm |
| Rider Max Height | 170 cm | 180 cm |
Model Overview
ALMA H20-EAGLE 27.5 is part of the Orbea Alma model. 83 bikes variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Orbea ALMA M50 27.5 2020 is the most economical model, with a starting price of 1999$. Orbea ALMA M-LTD 27.5 2020 on the other hand costs 7299$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
ALMA H20-EAGLE 27.5 components
Fork
The fork installed on this bike is the RockShox Judy Silver TK model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on ALMA H20-EAGLE 27.5 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ALMA H20-EAGLE 27.5 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
ALMA H20-EAGLE 27.5 comes in 2 sizes, that range from 155 cm – 180 cm (5.09 ft – 5.91 ft). In short, you can easily find one that suits you.
