Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork RockShox 30 Silver TK
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
178cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Alma Hydro Alloy, Boost 12x148, BSA BB, Internal cable routing.
Suspension Fork
RockShox 30 Silver TK Crown adjust QR Solo Air 100
Drivetrain
Rear Derailleur
Shimano Deore M5100 SGS Shadow Plus
Shift Levers
Shimano Deore M5100
Cassette
Sun Race 11-51t 11-Speed
Crank
OC1 Alloy forged Boost 32t
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC X11
Pedals
N/A
Wheels
Rims
Orbea Black Rock 23c Disc
Tires
Maxxis Ikon 2.20" FB 60 TPI Dual
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
Alloy 31.8mm interface 7º
Handlebar
OC1 Flat 31.8mm 740mm
Headset
FSA 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Royal 2058 DRN
Seatpost
Alloy 27.2 Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.524 mm | 1.437 mm | 1.386 mm | 1.34 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 664 mm | 699 mm | 724 mm | 756 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm |
| Stack | 602 mm | 612 mm | 621 mm | 635 mm |
| Reach | 395 mm | 426 mm | 448 mm | 474 mm |
| Top Tube Length | 562 mm | 596 mm | 620 mm | 650 |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1092 mm | 1127 mm | 1152 mm | 1184 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 721 mm | 735 mm | 791 mm | 829 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 178 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
Model Overview
ALMA H50 belongs to the Orbea Alma model. Orbea released 83 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Orbea ALMA H50 2022 is the cheapest bike model and costs 1167$. Orbea ALMA M LTD 2022 is the most expensive one and costs 9024$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Orbea released this model in 2022, its price was 1167$. If we compare this with the average Crosscountry bike cost we notice that the price is 63.24% smaller.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
ALMA H50 components
Fork
The fork installed on this bike is the RockShox 30 Silver TK model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Orbea ALMA H50 2022, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The ALMA H50 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Orbea ALMA H50 bike has 4 sizes, in the range of 155 cm – 198 cm (5.09 ft – 6.5 ft). In short, you can easily find one that suits you.
