Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox 30 Silver TK
-
Groupset SLX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Alma Hydro Boost141 Triple Butted 4X4 Taper PF Race
Suspension Fork
RockShox 30 Silver TK Crown adjust QR Solo Air 100
Drivetrain
Rear Derailleur
Shimano SLX M7000 GS Shadow Plus Direct Mount
Shift Levers
Shimano SLX M7000
Cassette
Sun Race CSMS8 11-46t 11-Speed
Crank
OC1 Alloy forged Integrated spindle Boost 32t 11S
Chain
KMC X11
Wheels
Rims
Orbea Black Rock 23c Disc
Tires
Maxxis Ikon 2.20" FB 60 TPI Dual
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
Alloy 31.8mm interface 7º
Handlebar
Alloy Flat 31.8mm 720mm
Headset
FSA 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Royal 2058 DRN
Seatpost
Alloy 27.2 Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.529 mm | 1.443 mm |
| Bottom Bracket Height | 312 mm | 312 mm |
| Front Center | 624 mm | 657 mm |
| Rake | 44 mm | 44 mm |
| Trail | 101 mm | 100 mm |
| Stack | 581 mm | 590 mm |
| Reach | 380 mm | 409 mm |
| Top Tube Length | 550 mm | 582 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 445 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 105 mm | 115 mm |
| Chainstay Length | 425 mm | 425 mm |
| Wheelbase | 1045 mm | 1078 mm |
| Bottom Bracket Drop | 43 mm | 43 mm |
| Standover Height | 716 mm | 735 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 155 cm | 165 cm |
| Rider Max Height | 170 cm | 180 cm |
About this model
ALMA H50 27.5 belongs to the Orbea Alma model. There are 83 bikes that carry this model name. Take a sneak peek at all Orbea Alma bikes models from 2020, by clicking here.
Model range prices
Orbea ALMA M50 27.5 2020 is the most affordable bike of this model and has a price of 1999$. On the other hand, Orbea ALMA M-LTD 27.5 2020, is the most expensive and costs 7299$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
ALMA H50 27.5 components
Fork
The RockShox 30 Silver TK is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The ALMA H50 27.5 2020 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea ALMA H50 27.5 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
ALMA H50 27.5 comes in 2 sizes, that range from 155 cm – 180 cm (5.09 ft – 5.91 ft). In conclusion, finding one for you shouldn’t be a problem.
