Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Groupset XX1 Eagle AXS -
Suspension Rigid -
Battery SRAM Powerpack -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
178cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Alma Carbon OMX, Boost 12x148, PF BB, Internal cable routing.
Suspension Fork
Orbea Spirit Rigid Carbon 15x110
Drivetrain
Rear Derailleur
SRAM XX1 Eagle AXS
Shift Levers
SRAM XX1 Eagle AXS
Cassette
SRAM XX1 XG-1299 Eagle 10-50t 12-Speed Rainbow
Crank
SRAM XX1 Eagle Dub Grey Boost 34t
Chain
SRAM XX1 Eagle 12-Speed rainbow
Chain Guide
Orbea Alma Carbon OMR & OMX. Compatible up to 36T
Wheels
Rims
DT Swiss XRC-1200 Spline 30c TLR 15/110mm CL
Tires
Maxxis Rekon Race 2.35" 120 TPI Exo TLR
Brakes
Brakes
SRAM Ultimate Carbon Stealth-a-majig Black Hydraulic Disc
Cockpit
Stem
OC3 31.8mm interface -8º
Handlebar
OC3 Carbon Flat 31.8mm 760mm
Headset
Acros 1-1/8 - 1-1/2" Semi-intergated Block Lock
Seat
Saddle
Selle Italia SLR Boost Fill Carbon Keramic Rail Ø7 x 9 mm
Seatpost
OC2 Carbon 27.2 Offset 0
Motor & Battery
Battery
SRAM Powerpack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.501 mm | 1.413 mm | 1.366 mm | 1.319 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 660 mm | 695 mm | 721 mm | 752 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm |
| Stack | 593 mm | 602 mm | 612 mm | 625 mm |
| Reach | 395 mm | 426 mm | 448 mm | 474 mm |
| Top Tube Length | 559 mm | 593 mm | 618 mm | 647 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1083 mm | 1118 mm | 1144 mm | 1175 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 693 mm | 729 mm | 749 mm | 819 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 178 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
About this model
ALMA M LTD completes the Orbea Alma model. Orbea launched 83 bikes of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Orbea ALMA H50 2021 is the most affordable bike of this model and has a price of 1167$. On the other hand, Orbea ALMA M LTD 2021, is the most expensive and costs 8599$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 8599$. Comparing this to the average Crosscountry bike price, we see that the price is 351.39% more expensive.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
ALMA M LTD components
Fork material
ALMA M LTD has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Orbea ALMA M LTD 2021, has a 29″ carbon model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The ALMA M LTD has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Orbea ALMA M LTD bike has 4 sizes, in the range of 155 cm – 198 cm (5.09 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
