Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Groupset XX1 Eagle AXS -
Suspension Rigid -
Battery SRAM Powerpack -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
178cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Alma Carbon OMX, Boost 12x148, PF BB, Internal cable routing.
Suspension Fork
Orbea Spirit Rigid Carbon 15x110
Drivetrain
Rear Derailleur
SRAM XX1 Eagle AXS
Shift Levers
SRAM XX1 Eagle AXS
Cassette
SRAM XX1 XG-1299 Eagle 10-50t 12-Speed Rainbow
Crank
SRAM XX1 Eagle Dub Grey Boost 34t
Chain
SRAM XX1 Eagle 12-Speed rainbow
Chain Guide
Orbea Alma Carbon OMR & OMX. Compatible up to 36T
Wheels
Rims
OQUO Mountain Performance MP30LTD Carbon
Tires
Maxxis Rekon Race 2.40" WT 120 TPI Exo TLR
Brakes
Brakes
SRAM Ultimate Carbon Black Hydraulic Disc
Cockpit
Stem
OC Mountain Performance MP20, -8º
Handlebar
OC MP10 Mountain Performance Carbon, Width 760, Sweep 9
Headset
Acros 1-1/8 - 1-1/2" Semi-intergated Block Lock
Seat
Saddle
Selle Italia SLR Boost Fill Carbon Rail Ø7x9 mm
Seatpost
OC Performance XP10 Carbon, 27.2mm, Setback 0
Motor & Battery
Battery
SRAM Powerpack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.501 mm | 1.413 mm | 1.366 mm | 1.319 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 660 mm | 695 mm | 721 mm | 752 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm |
| Stack | 593 mm | 602 mm | 612 mm | 625 mm |
| Reach | 395 mm | 426 mm | 448 mm | 474 mm |
| Top Tube Length | 559 mm | 593 mm | 618 mm | 647 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1083 mm | 1118 mm | 1144 mm | 1175 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 693 mm | 729 mm | 767 mm | 819 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 178 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
About this model
ALMA M LTD is part of the Orbea Alma model. There are 83 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Orbea ALMA M10 2023 is the most economical model, with a starting price of 4399$. Orbea ALMA M LTD 2023 on the other hand costs 8599$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 8599$. Comparing this to the average Crosscountry bike price, we see that the price is 351.39% more expensive.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
ALMA M LTD components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on ALMA M LTD are the 29″ carbon type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea ALMA M LTD has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Orbea ALMA M LTD bike has 4 sizes, in the range of 155 cm – 198 cm (5.09 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
