Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Avant Hydro, hydroformed triple butted aluminum, headset 1-1/8", BB 68mm - BSC English, internal cable routing, 130 OLD, 27,2mm seat tube.
Suspension Fork
Avant carbon fork, aluminum steerer, 1-1/8" head tube
Drivetrain
Rear Derailleur
Shimano Sora 3000GS
Front Derailleur
Shimano Sora 3000
Shift Levers
Shimano Sora
Cassette
Shimano HG400 11-32t 9-Speed
Crank
Shimano Sora R3000 34x50t
Bottom Bracket
BSA, 68mm, threaded
Chain
Shimano HG53 9-Speed
Pedals
VP-335T
Wheels
Rims
Orbea R1800
Tires
Vittoria Zafiro IV 700x25 26TPI
Brakes
Brakes
Orbea OC-II
Cockpit
Stem
Orbea OC-II
Handlebar
Orbea OC-II
Headset
1-1/8" Semi-Integrated Aluminium Cup
Seat
Saddle
Selle Royal Seta RS
Seatpost
Orbea OC-I 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.47 mm | 1.51 mm | 1.52 mm | 1.57 mm | 1.58 mm | 1.6 mm |
| Bottom Bracket Height | 257.5 mm | 257.5 mm | 257.5 mm | 257.5 mm | 257.5 mm | 257.5 mm | 257.5 mm |
| Front Center | 575 mm | 583 mm | 590 mm | 591 mm | 598 mm | 607 mm | 616 mm |
| Rake | 53 mm | 53 mm | 53 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 59 mm | 58 mm | 56 mm | 65 mm | 62 mm | 59 mm | 56 mm |
| Stack | 510.4 mm | 528.8 mm | 547.8 mm | 565.8 mm | 589.1 mm | 607.6 mm | 629.5 mm |
| Reach | 356 mm | 360.1 mm | 363.9 mm | 371.4 mm | 376.4 mm | 384.7 mm | 393.2 mm |
| Top Tube Length | 509.2 mm | 520.3 mm | 529.5 mm | 542.1 mm | 556.9 mm | 572.6 mm | 587.4 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 71.2 ° | 71.4 ° | 71.8 ° | 72 ° | 72.5 ° | 73 ° | 73.5 ° |
| Head Tube Length | 113 mm | 131.7 mm | 150.1 mm | 165 mm | 188 mm | 205 mm | 226 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 971 mm | 979 mm | 985 mm | 986 mm | 998 mm | 1007 mm | 1016 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 714 mm | 723 mm | 747 mm | 767 mm | 791 mm | 813 mm | 840 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
About this model
AVANT H50 is an Orbea Avant model. 41 bikes variations carry this model name so far. Take a sneak peek at all Orbea Avant bikes models from 2018, by clicking here.
Model range prices
Orbea AVANT H50 2018 is the most economical model, with a starting price of 1049$. Orbea AVANT M10iTEAM-D 2018 on the other hand costs 7999$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Endurance bikes average price
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2018 for 1049$. Doing a quick comparison, we notice that AVANT H50 price is 123.64% smaller than the average cost of an Endurance bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The AVANT H50 2018 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The AVANT H50 comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Orbea AVANT H50 bike has 7 sizes, in the range of 155 cm – 207 cm (5.09 ft – 6.79 ft). In short, you can easily find one that suits you.
