Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Avant Hydro, hydroformed triple butted aluminum, headset 1-1/8", BB 68mm - BSC English, internal cable routing, 130 OLD, 27,2mm seat tube.
Suspension Fork
Orbea Avant carbon fork, aluminum steerer, 1-1/8" head tube
Drivetrain
Rear Derailleur
Shimano Sora 3000GS
Front Derailleur
Shimano Sora 3000
Shift Levers
Shimano Sora
Cassette
Shimano HG400 11-32t 9-Speed
Crank
Shimano Sora R3000 34x50t
Bottom Bracket
BSA, 68mm, threaded
Chain
Shimano HG53 9-Speed
Wheels
Rims
Orbea R1800
Tires
Vittoria Zafiro IV 700x25
Brakes
Brakes
Orbea OC-II
Cockpit
Stem
OC1 31.8mm interface -7º
Handlebar
OC1 Road, reach 80mm, drop 125mm
Headset
1-1/8" Semi-Integrated Aluminium Cup
Seat
Saddle
Selle Royal Seta RS
Seatpost
Alloy 27.2 Offset 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.47 mm | 1.51 mm | 1.52 mm | 1.57 mm | 1.58 mm | 1.6 mm |
| Bottom Bracket Height | 257.5 mm | 257.5 mm | 257.5 mm | 257.5 mm | 257.5 mm | 257.5 mm | 257.5 mm |
| Front Center | 575 mm | 583 mm | 590 mm | 591 mm | 598 mm | 607 mm | 616 mm |
| Rake | 53 mm | 53 mm | 53 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 59 mm | 58 mm | 56 mm | 65 mm | 62 mm | 59 mm | 56 mm |
| Stack | 510.4 mm | 528.8 mm | 547.8 mm | 565.8 mm | 589.1 mm | 607.6 mm | 629.5 mm |
| Reach | 356 mm | 360.1 mm | 363.9 mm | 371.4 mm | 376.4 mm | 384.7 mm | 393.2 mm |
| Top Tube Length | 509.2 mm | 520.3 mm | 529.5 mm | 542.1 mm | 556.9 mm | 572.6 mm | 587.4 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 71.2 ° | 71.4 ° | 71.8 ° | 72 ° | 72.5 ° | 73 ° | 73.5 ° |
| Head Tube Length | 113 mm | 131.7 mm | 150.1 mm | 165 mm | 188 mm | 205 mm | 226 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 971 mm | 979 mm | 985 mm | 986 mm | 998 mm | 1007 mm | 1016 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 714 mm | 723 mm | 747 mm | 767 mm | 791 mm | 813 mm | 840 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
About this model
AVANT H50 completes the Orbea Avant model. Orbea launched 41 bikes of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Orbea AVANT H50 2021 is the cheapest bike model and costs 1142$. Orbea AVANT H30-D 2021 is the most expensive one and costs 1999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Orbea released this model in 2021, its price was 1142$. In conclusion, this bike price is 105.43% smaller than the price of the average Endurance bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
AVANT H50 components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The AVANT H50 2021 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The AVANT H50 has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
This bike is available in 7 sizes. They vary from 155 cm – 207 cm (5.09 ft – 6.79 ft). In conclusion, it won’t take much to find one that’s right for you.
