Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Avant Hydro disc, hydroformed triple butted aluminium, HS 1,5" ICR, BB 68mm – BSC English, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, SP 27,2mm, MMS system.
Suspension Fork
Orbea carbon fork 2021, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1, Speed release compatible dropout.
Drivetrain
Rear Derailleur
Shimano Claris RD-R2000-GS
Front Derailleur
Shimano Claris FD-R2000-F
Shift Levers
Shimano Claris ST-R2000
Cassette
Shimano HG50 11-32t 8-Speed
Crank
Shimano Claris R2000 34x50t
Bottom Bracket
BSA, 68mm, threaded
Chain
KMC X8
Wheels
Rims
Alloy, Tubeless, 700c, 19c, 28H
Tires
Vittoria Zafiro V Rigid bead 700x28c
Brakes
Brakes
Jagwire RideRever Mechanical Disc
Cockpit
Stem
OC Road Performance RP21, -6º
Handlebar
OC Road Perfornace RP31-R, Rise 15, Reach 70, Drop 125
Headset
Acros Alloy 1-1/2" Internal Cable Routing
Seat
Saddle
Fizik Aliante R5
Seatpost
Alloy, 27.2mm, Setback 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.47 mm | 1.5 mm | 1.54 mm | 1.55 mm | 1.58 mm | 1.61 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 576 mm | 583 mm | 590 mm | 592 mm | 606 mm | 615 mm | 624 mm |
| Rake | 48 mm | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 66 mm | 63 mm | 60 mm | 62 mm | 61 mm | 61 mm | 60 mm |
| Stack | 528 mm | 548 mm | 568 mm | 588 mm | 608 mm | 628 mm | 648 mm |
| Reach | 368 mm | 373 mm | 378 mm | 383 mm | 393 mm | 398 mm | 403 mm |
| Top Tube Length | 514 mm | 529 mm | 542 mm | 556 mm | 572 mm | 589 mm | 600 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.75 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 445 mm | 470 mm | 495 mm | 520 mm | 545 mm | 575 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.9 ° | 72.4 ° | 72.6 ° | 72.8 ° | 73 ° |
| Head Tube Length | 122 mm | 141 mm | 161 mm | 180 mm | 201 mm | 221 mm | 241 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 992 mm | 999 mm | 1007 mm | 1009 mm | 1023 mm | 1032 mm | 1041 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 716 mm | 741 mm | 764 mm | 793 mm | 812 mm | 836 mm | 855 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
Model Overview
AVANT H60 is an Orbea Avant model. Orbea launched 41 bikes of this model so far. Take a sneak peek at all Orbea Avant bikes models from 2023, by clicking here.
Model range prices
Orbea AVANT H60 2023 is the most affordable bike of this model and has a price of 1699$. On the other hand, Orbea AVANT H40 2023, is the most expensive and costs 1899$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Endurance bikes average price
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Orbea AVANT H60 price was 1699$. Comparing the average cost of an Endurance bike to this one, you will see that AVANT H60 price is 38.08% lower.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
AVANT H60 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Orbea AVANT H60 2023, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea AVANT H60 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Orbea AVANT H60 bike has 7 sizes, in the range of 155 cm – 207 cm (5.09 ft – 6.79 ft). In short, you can easily find one that suits you.
