Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Motor hub-drive -
Battery Ebikemotion 36V/6.9A -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
159cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Gain Hydro, Aluminum 6000 series, Orbea Tube Shaping, Flat Mount Disc Brakes, 135x9 QR, Carrier and Mudguards compatible, max 700x40C, Inner Cable routing, Ebikemotion X35 specific, integrated battery, in
Suspension Fork
Speed 400mm Carbon Flat mount
Drivetrain
Rear Derailleur
Shimano Claris RD-R2000-GS
Front Derailleur
Shimano Claris FD-R2000-F
Shift Levers
Shimano Claris SL-R2000
Cassette
Shimano HG50 11-34t 8-Speed
Crank
Shimano Claris R2000 34x50t
Chain
KMC X8
Pedals
VP-537 Black
Wheels
Front Hub
Safety Lock
Rims
Airline Corsa
Tires
Kenda K1067 700x38C Reflective type+puncture protection
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Orbea OC-II
Handlebar
Orbea OC-I Riser 640mm
Headset
1-1/8" Semi-Integrated
Seat
Saddle
Selle Royal Scientia A2
Seatpost
Orbea OC-I 27.2x350mm
Motor & Battery
Motor
Ebikemotion X35
Battery
Ebikemotion 36V/6.9A
Charger
Ebikemotion X35
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.44 mm | 1.47 mm | 1.5 mm | 1.53 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 283 mm | 283 mm | 285 mm |
| Front Center | 596 mm | 602 mm | 616 mm | 630 mm | 645 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 63 mm | 57 mm | 58 mm | 59 mm | 55 mm |
| Stack | 527 mm | 547 mm | 567 mm | 592 mm | 617 mm |
| Reach | 370 mm | 379 mm | 387 mm | 394 mm | 402 mm |
| Top Tube Length | 514 mm | 538 mm | 552 mm | 566 mm | 587 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 460 mm | 510 mm | 555 mm | 585 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72.3 ° |
| Head Tube Length | 109 mm | 127 mm | 150 mm | 176 mm | 203 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1008 mm | 1014 mm | 1029 mm | 1043 mm | 1059 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 68 mm | 68 mm | 66 mm |
| Standover Height | 746 mm | 774 mm | 807 mm | 821 mm | 868 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 161 cm | 171 cm | 181 cm | 191 cm | cm |
Model Overview
GAIN F30 USA completes the Orbea E Gain model. 78 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Orbea GAIN F30 USA 2019 is the most economical model, with a starting price of 2499$. Orbea GAIN M20i USA 2019 on the other hand costs 5799$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance e-bikes
Our math shows that the average cost of a dependable Endurance e-bike is 3800$. However, this doesn’t mean that if you spend less money on an Endurance e-bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Orbea GAIN F30 USA price was 2499$. Comparing this to the average Endurance e-bike price, we see that the price is 52.06% lower.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your e-bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When it comes to wheels, the GAIN F30 USA e-bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
