Orbea GAIN M21e 1X 20mph 2024
2024 E-bike
Estimate price |
7,699$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force XPLR eTap, Force eTap -
Suspension Rigid -
Motor MAHLE 55Nm hub-drive -
Battery Mahle iX350 36V 353Wh -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
165cm - 174cm
MD
171cm - 181cm
LG
178cm - 187cm
XL
184cm - 193cm
XXL
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disc, 700x35 max tyre, BB386 EVO, Mahle X20 AMC plug.
Suspension Fork
Gain OMR carbon fork, 700x35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1
Drivetrain
Rear Derailleur
SRAM Force XPLR AXS 12s
Shift Levers
SRAM Force AXS
Cassette
SRAM XG-1271 XPLR 10-44t 12-Speed
Crank
SRAM Force Dub Wide 40t
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM Force 12-Speed
Wheels
Rims
Alloy, Tubeless, 700c, 21c
Tires
Pirelli Cinturato™ Gravel H 700x35c TLR
Brakes
Brakes
SRAM Force AXS
Cockpit
Stem
OC Road Performance RP10, -8º
Handlebar
OC Gravel GR31, Reach 70, Drop 110
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Fizik Aliante R5
Seatpost
OC Performance XP10 Carbon, 27.2mm, Setback 0
Motor & Battery
Motor
Mahle motor hub X20, ALC
Battery
Mahle iX350 36V 353Wh
Remote
Mahle ONE Head Unit (BT/ANT+)
Charger
Mahle Active Charger up to 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.419 mm | 1.447 mm | 1.474 mm | 1.5 mm | 1.525 mm | 1.549 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 582 mm | 596 mm | 608 mm | 619 mm | 632 mm | 644 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 64.5 mm | 63.3 mm | 61.4 mm | 58 mm | 57 mm | 55 mm |
| Stack | 525 mm | 547 mm | 569 mm | 591 mm | 613 mm | 635 mm |
| Reach | 370 mm | 378 mm | 386 mm | 394 mm | 402 mm | 410 mm |
| Top Tube Length | 516 mm | 535 mm | 555 mm | 569 mm | 587 mm | 602 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 430 mm | 460 mm | 490 mm | 515 mm | 540 mm | 570 mm |
| Head Tube Angle | 71 ° | 71.2 ° | 71.5 ° | 72 ° | 72.2 ° | 72.5 ° |
| Head Tube Length | 113 mm | 136 mm | 158 mm | 181 mm | 203 mm | 225 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 984 mm | 998 mm | 1011 mm | 1022 mm | 1035 mm | 1047 mm |
| Bottom Bracket Drop | 78 mm | 78 mm | 78 mm | 76 mm | 76 mm | 76 mm |
| Standover Height | 728 mm | 756 mm | 782 mm | 803 mm | 830 mm | 844 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
About this model
GAIN M21e 1X 20mph is an Orbea E Gain model. Orbea released 84 e-bikes variations of this model so far. Take a sneak peek at all Orbea E Gain e-bikes models from 2024, by clicking here.
Model range prices
Orbea GAIN M31e 1X 2024 is the most affordable e-bike of this model and has a price of 6988$. On the other hand, Orbea GAIN M10i 2024, is the most expensive and costs 10588$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Endurance e-bikes
According to our calculations, the average cost of an Endurance e-bike that is reliable is 3800$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2024 and its price was 7699$. Comparing the average cost of an Endurance e-bike to this one, you will see that GAIN M21e 1X 20mph price is 102.61% more expensive.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
GAIN M21e 1X 20mph components
Fork material
GAIN M21e 1X 20mph has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the GAIN M21e 1X 20mph model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The GAIN M21e 1X 20mph comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Orbea GAIN M21e 1X 20mph e-bike has 6 sizes, in the range of 155 cm – 207 cm (5.09 ft – 6.79 ft). In conclusion, you won’t have a problem finding one that suits you.
