Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Marzocchi Bomber Z2
-
Groupset Deore -
Suspension Hardtail -
Motor Shimano mid-drive -
Battery Orbea Internal 540Wh (Optional 250 Wh Range Extender) -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Kemen Top Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible
Suspension Fork
Marzocchi Bomber Z2 100 QR15x110 E-Bike Optimized
Drivetrain
Rear Derailleur
Shimano Deore M5130 Link Glide GS Shadow Plus
Shift Levers
Shimano Deore M5130 Link Glide
Cassette
Shimano CS-LG400 11-43t 10-Speed
Crank
Alloy EP8 36t w/chainguard
Bottom Bracket
STEPS, press-fit
Chain
KMC eGlide
Pedals
VP-537 Black
Wheels
Rims
Alloy, Tubeless, 25c, 32H
Tires
Schwalbe G-ONE Allround, 29x2,25, Performance Line RaceGuard, TLE, Reflective
Brakes
Brakes
Magura MT30 Hydraulic Disc Easy Route Connection
Cockpit
Stem
Alloy forged, 35mm interface, -6º, ICR
Handlebar
OC Mountain Control MC31, Rise20, Width 800
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Selle Royal Vivo 145x269mm
Seatpost
Alloy, 31.6mm, Setback 0
Motor & Battery
Motor
Shimano EP801
Battery
Orbea Internal 540Wh (Optional 250 Wh Range Extender)
Remote
EN600-L
Charger
Orbea 2.Generation eBike Smart charger 42V/2-4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.523 mm | 1.504 mm | 1.455 mm | 1.402 mm |
| Bottom Bracket Height | 307.5 mm | 307.5 mm | 307.5 mm | 307.5 mm |
| Front Center | 696 mm | 704 mm | 444272 mm | 444234 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 113 mm | 109 mm | 109 mm | 445105 mm |
| Stack | 617 mm | 624 mm | 640 mm | 659 mm |
| Reach | 405 mm | 415 mm | 440 mm | 470 mm |
| Top Tube Length | 563 mm | 576 mm | 606 mm | 642 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 453 mm | 483 mm | 533 mm |
| Head Tube Angle | 66.5 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 110 mm | 115 mm | 132 mm | 153 mm |
| Chainstay Length | 445 mm | 445 mm | mm | mm |
| Wheelbase | 1134 mm | 1142 mm | 1173 mm | 1211 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 781 mm | 810 mm | 833 mm | 866 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 200 cm |
About this model
KEMEN 30 is an Orbea E Kemen model. Orbea released 47 e-bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Orbea KEMEN SUV 40 20mph 2023 is the most affordable e-bike of this model and has a price of 3699$. On the other hand, Orbea KEMEN 10 2023, is the most expensive and costs 5716$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Commuter e-bikes average price
If you want an acceptable Commuter e-bike you should know that the average price is 2569$. However, you could also get a good Commuter e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 4864$. In conclusion, this e-bike price is 89.33% more expensive than the price of the average Commuter e-bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The fork installed on this bike is the Marzocchi Bomber Z2 model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
As for the wheels, Orbea KEMEN 30 2023, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea KEMEN 30 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
KEMEN 30 comes in 4 sizes, that range from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
