Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 100mm -
Fork Suntour XCR Air
-
Groupset Acera, Shimano -
Suspension Hardtail -
Motor Shimano 250W 85Nm mid-drive -
Battery Orbea Internal 540Wh (Optional 250 Wh Range Extender) -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Kemen Top Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible
Suspension Fork
SR Suntour XCR34 LO R Air 100mm Q15x110 Boost
Drivetrain
Rear Derailleur
Shimano Acera M3020
Shift Levers
Shimano SL-M315
Cassette
Shimano CS-HG400 11-40t 8-Speed
Crank
Alloy EP8 36t w/chainguard
Bottom Bracket
STEPS, press-fit
Chain
KMC X8
Pedals
VP-537 Black
Wheels
Rims
Alloy, Tubeless, 29", 29c, 32H
Tires
Urban 47-622, Puncture Protection, Reflex
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Alloy forged, 35mm interface, -6º, ICR
Handlebar
OC Mountain Control MC31, Rise20, Width 800
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Selle Royal Vivo Ergo
Seatpost
Alloy 31.6x300mm Offset 0
Motor & Battery
Motor
Shimano EP600
Battery
Orbea Internal 540Wh (Optional 250 Wh Range Extender)
Charger
Orbea 2.Generation eBike Smart charger 42V/2-4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.523 mm | 1.504 mm | 1.455 mm | 1.402 mm |
| Bottom Bracket Height | 307.5 mm | 307.5 mm | 307.5 mm | 307.5 mm |
| Front Center | 696 mm | 704 mm | 444272 mm | 444234 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 113 mm | 109 mm | 109 mm | 445105 mm |
| Stack | 617 mm | 624 mm | 640 mm | 659 mm |
| Reach | 405 mm | 415 mm | 440 mm | 470 mm |
| Top Tube Length | 563 mm | 576 mm | 606 mm | 642 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 453 mm | 483 mm | 533 mm |
| Head Tube Angle | 66.5 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 110 mm | 115 mm | 132 mm | 153 mm |
| Chainstay Length | 445 mm | 445 mm | mm | mm |
| Wheelbase | 1134 mm | 1142 mm | 1173 mm | 1211 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 781 mm | 810 mm | 833 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 200 cm |
About this model
KEMEN 40 is an Orbea E Kemen model. Orbea released 47 e-bikes variations of this model so far. Take a sneak peek at all Orbea E Kemen e-bikes models from 2024, by clicking here.
Model range prices
The most economical model, the Orbea KEMEN 40 2024 has a starting price of 4013$. Orbea KEMEN 10 2024 on the other hand is the most expensive at 5594$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Commuter e-bikes
If you want to purchase a solid Commuter e-bike, it is important to know that the average cost is 2569$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2024 and its price was 4013$. Comparing this to the average Commuter e-bike price, we see that the price is 56.21% higher.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
KEMEN 40 components
Fork
The Suntour XCR Air is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When it comes to wheels, the KEMEN 40 e-bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
KEMEN 40 comes in 4 sizes, that range from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
