Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Fox AWL
-
Groupset XT -
Suspension Hardtail -
Motor Shimano 250W 85Nm mid-drive -
Battery Orbea Internal 540Wh (Optional 252Wh Range Extender) -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Kemen Mid Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible
Suspension Fork
Fox 34 Float AWL 100 RAIL QR15x110
Drivetrain
Rear Derailleur
Shimano XT M8130 Link Glide SGS Shadow Plus
Shift Levers
Shimano XT M8130 Link Glide
Cassette
Shimano CS-LG600 11-50t 11-Speed
Crank
Alloy EP8 36t w/chainguard
Bottom Bracket
STEPS, press-fit
Chain
Shimano LG500
Pedals
VP-537 Black
Wheels
Rims
Alloy, Tubeless, 25c, 32H
Tires
Schwalbe G-ONE Allround, 29x2,25, Performance Line RaceGuard, TLE, Reflective
Brakes
Brakes
Magura MT5 E-STOP Hydraulic Disc Easy Route Connection
Cockpit
Stem
Alloy forged, 35mm interface, -6º, ICR
Handlebar
Alloy, 35mm, Rise 20mm, 780mm
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Selle Royal Vivo 1216 DRN 160x249mm
Seatpost
OC Mountain Control MC20, 31.6mm, Dropper
Motor & Battery
Motor
Shimano EP8
Battery
Orbea Internal 540Wh (Optional 252Wh Range Extender)
Remote
RS
Charger
Orbea Smart Charger (42V-4A)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.523 mm | 1.504 mm | 1.455 mm |
| Bottom Bracket Height | 307.5 mm | 307.5 mm | 307.5 mm |
| Front Center | 696 mm | 704 mm | 735 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 104 mm | 99 mm | 100 mm |
| Stack | 617 mm | 624 mm | 640 mm |
| Reach | 405 mm | 415 mm | 440 mm |
| Top Tube Length | 563 mm | 576 mm | 606 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 453 mm | 483 mm |
| Head Tube Angle | 66.5 ° | 67 ° | 67 ° |
| Head Tube Length | 110 mm | 115 mm | 132 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1134 mm | 1142 mm | 1173 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm |
| Standover Height | 732 mm | 740 mm | 743 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 175 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm |
About this model
KEMEN MID 10 is part of the Orbea E Kemen model. There are 47 e-bikes that carry this model name. You can easily view all of the Orbea E Kemen e-bikes models from 2023, here.
Model range prices
Orbea KEMEN SUV 40 20mph 2023 is the most affordable e-bike of this model and has a price of 3699$. On the other hand, Orbea KEMEN 10 2023, is the most expensive and costs 5716$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Commuter e-bikes average price
If you want to purchase a solid Commuter e-bike, it is important to know that the average cost is 2569$. However, you could also get a good Commuter e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5229$. If we compare this with the average Commuter e-bike cost we notice that the price is 103.54% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The Fox AWL is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The KEMEN MID 10 2023 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The KEMEN MID 10 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 155 cm – 190 cm (5.09 ft – 6.23 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
