Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Marzocchi Bomber Z2
-
Groupset Deore -
Suspension Hardtail -
Motor Shimano 250W 85Nm mid-drive -
Battery Orbea Internal 540Wh (Optional 252Wh Range Extender) -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Kemen Mid Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible
Suspension Fork
Marzocchi Bomber Z2 100 QR15x110 E-Bike Optimized
Drivetrain
Rear Derailleur
Shimano Deore M5130 Link Glide GS Shadow Plus
Shift Levers
Shimano Deore M5130 Link Glide
Cassette
Shimano CS-LG600 11-43t 10-Speed
Crank
Alloy EP8 36t w/chainguard
Bottom Bracket
STEPS, press-fit
Chain
Shimano LG500
Pedals
VP-537 Black
Wheels
Rims
Alloy, Tubeless, 25c, 32H
Tires
Schwalbe G-ONE Allround, 29x2,25, Performance Line RaceGuard, TLE, Reflective
Brakes
Brakes
Magura MT30 Hydraulic Disc Easy Route Connection
Cockpit
Stem
Alloy forged, 35mm interface, -6º, ICR
Handlebar
Alloy, 35mm, Rise 20mm, 780mm
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Selle Royal Vivo 1216 DRN 160x249mm
Seatpost
Alloy, 31.6mm, Setback 0
Motor & Battery
Motor
Shimano EP8
Battery
Orbea Internal 540Wh (Optional 252Wh Range Extender)
Charger
Orbea Smart Charger (42V-4A)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.523 mm | 1.504 mm | 1.455 mm |
| Bottom Bracket Height | 307.5 mm | 307.5 mm | 307.5 mm |
| Front Center | 696 mm | 704 mm | 735 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 104 mm | 99 mm | 100 mm |
| Stack | 617 mm | 624 mm | 640 mm |
| Reach | 405 mm | 415 mm | 440 mm |
| Top Tube Length | 563 mm | 576 mm | 606 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 453 mm | 483 mm |
| Head Tube Angle | 66.5 ° | 67 ° | 67 ° |
| Head Tube Length | 110 mm | 115 mm | 132 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1134 mm | 1142 mm | 1173 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm |
| Standover Height | 732 mm | 740 mm | 743 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 175 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm |
Model Overview
KEMEN MID 30 is part of the Orbea E Kemen model. Orbea launched 47 e-bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Orbea KEMEN 30 2022 is the most affordable e-bike of this model and has a price of 4378$. On the other hand, Orbea KEMEN SUV 10 20mph 2022, is the most expensive and costs 5499$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Commuter e-bikes average price
Our math shows that the average cost of a dependable Commuter e-bike is 2569$. However, you could also get a good Commuter e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4378$. Doing a quick comparison, we notice that KEMEN MID 30 price is 70.42% more expensive than the average cost of a Commuter e-bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
This e-bike has the Marzocchi Bomber Z2 fork installed. The fork’s travel is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the KEMEN MID 30 e-bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea KEMEN MID 30 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Orbea KEMEN MID 30 e-bike has 3 sizes, in the range of 155 cm – 190 cm (5.09 ft – 6.23 ft). In conclusion, you won’t have a problem finding one that suits you.
