Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Marzocchi Bomber Z2
-
Groupset Deore -
Suspension Hardtail -
Motor Shimano 250W 85Nm mid-drive -
Battery Orbea Internal 540Wh (Optional 252Wh Range Extender) -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Kemen Mid Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible
Suspension Fork
Marzocchi Bomber Z2 100 QR15x110 E-Bike Optimized
Drivetrain
Rear Derailleur
Shimano Deore M5130 Link Glide GS Shadow Plus
Shift Levers
Shimano Deore M5130 Link Glide
Cassette
Shimano CS-LG600 11-43t 10-Speed
Crank
Alloy EP8 36t w/chainguard
Bottom Bracket
STEPS, press-fit
Chain
Shimano LG500
Pedals
VP-537 Black
Wheels
Rims
Alloy, Tubeless, 25c, 32H
Tires
Schwalbe G-ONE Allround, 29x2,25, Performance Line RaceGuard, TLE, Reflective
Brakes
Brakes
Magura MT30 Hydraulic Disc Easy Route Connection
Cockpit
Stem
Alloy forged, 35mm interface, -6º, ICR
Handlebar
Alloy, 35mm, Rise 20mm, 780mm
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Selle Royal Vivo 1216 DRN 160x249mm
Seatpost
Alloy, 31.6mm, Setback 0
Motor & Battery
Motor
Shimano EP8
Battery
Orbea Internal 540Wh (Optional 252Wh Range Extender)
Remote
EN600-L
Charger
Orbea Smart Charger (42V-4A)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.523 mm | 1.504 mm | 1.455 mm |
| Bottom Bracket Height | 307.5 mm | 307.5 mm | 307.5 mm |
| Front Center | 696 mm | 704 mm | 735 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 104 mm | 99 mm | 100 mm |
| Stack | 617 mm | 624 mm | 640 mm |
| Reach | 405 mm | 415 mm | 440 mm |
| Top Tube Length | 563 mm | 576 mm | 606 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 453 mm | 483 mm |
| Head Tube Angle | 66.5 ° | 67 ° | 67 ° |
| Head Tube Length | 110 mm | 115 mm | 132 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1134 mm | 1142 mm | 1173 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm |
| Standover Height | 732 mm | 740 mm | 743 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 175 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm |
Model Overview
KEMEN MID 30 is part of the Orbea E Kemen model. Orbea launched 47 e-bikes of this model so far. You can easily view all of the Orbea E Kemen e-bikes models from 2023, here.
Model range prices
Orbea KEMEN SUV 40 20mph 2023 is the most economical model, with a starting price of 3699$. Orbea KEMEN 10 2023 on the other hand costs 5716$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Commuter e-bikes average price
According to our math, the average price for a trustworthy Commuter e-bike is 2569$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
This e-bike was released in 2023 and its price was 4378$. Comparing the average cost of a Commuter e-bike to this one, you will see that KEMEN MID 30 price is 70.42% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
KEMEN MID 30 components
Fork
This e-bike has the Marzocchi Bomber Z2 fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the KEMEN MID 30 e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea KEMEN MID 30 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 155 cm – 190 cm (5.09 ft – 6.23 ft). In conclusion, it won’t take much to find one that’s right for you.
