Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 24" -
Travel Front 100mm -
Fork Manitou Machete Comp
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
20"
110cm - 135cm
24"
125cm - 150cm
27cm
140cm - 165cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey 24 6061 Aluminum 2021, 135x9 QR, Post Mount Disc Mount, 31,6 Seat Post, Internal Cable Routing, Removable hanger.
Suspension Fork
Manitou Machete JUNIT Comp 100mm QR15x110 Boost
Drivetrain
Rear Derailleur
Shimano Deore M5120 SGS Shadow Plus
Shift Levers
Shimano Deore M4100
Cassette
Sun Race 11-42t 10-Speed
Crank
Extra light 32t, 152mm, w/Chainguard
Chain
KMC X10
Chain Guide
Orbea OC chainguide
Pedals
VP-229 Black with reflectors
Wheels
Rims
Mach1 Klixx 23c Tubeless Ready
Tires
Schwalbe Rocket Ron Perf Foldable, 24x2.35
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
Race Face Ride
Handlebar
Alloy 31.8mm Riser 560mm
Seat
Saddle
Selle Royal Vivo Junior
Seatpost
OC MC20 Mountain Control Dropper, 31,6mm, 75mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 20" | 24" | 27cm |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.48 mm |
| Bottom Bracket Height | 248 mm | 288 mm | 315 mm |
| Front Center | 555 mm | 627 mm | 681 mm |
| Rake | 40 mm | 40 mm | 44 mm |
| Stack | 440 mm | 513 mm | 567 mm |
| Reach | 315 mm | 359 mm | 382 mm |
| Top Tube Length | 443 mm | 508 mm | 536 mm |
| Seat Tube Angle | 74 ° | 74 ° | 75 ° |
| Seat Tube Length | 257 mm | 300 mm | 343 mm |
| Head Tube Angle | 66 ° | 66 ° | 65.5 ° |
| Head Tube Length | 90 mm | 100 mm | 95 mm |
| Chainstay Length | 343 mm | 388 mm | 418 mm |
| Wheelbase | 897 mm | 1012 mm | 1095 mm |
| Bottom Bracket Drop | 23 mm | 35 mm | 43 mm |
| Standover Height | 498 mm | 586 mm | 629 mm |
| Wheels | 24" | 24" | 24" |
| Rider Min Height | 110 cm | 125 cm | 140 cm |
| Rider Max Height | 135 cm | 150 cm | 165 cm |
About this model
LAUFEY 24 H10 belongs to the Orbea Laufey model. 26 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Orbea LAUFEY 20 H30 2022 is the cheapest bike model and costs 678$. Orbea LAUFEY H-LTD 2022 is the most expensive one and costs 2441$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Mountain bikes
According to our math, the average price for a trustworthy Mountain bike is 616$. However, you could also get a good Mountain bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Orbea LAUFEY 24 H10 price was 1273$. If we compare this with the average Mountain bike cost we notice that the price is 106.66% more expensive.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The Manitou Machete Comp is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on LAUFEY 24 H10 are the 24″ aluminum type. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
When you want to stop the bike in time, the brakes are vital. The LAUFEY 24 H10 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
LAUFEY 24 H10 comes in 3 sizes, that range from 110 cm – 165 cm (3.61 ft – 5.41 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Orbea LAUFEY 24 H10 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
