Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 120mm -
Fork Marzocchi Bomber Z2
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
20"
110cm - 135cm
24"
125cm - 150cm
27cm
140cm - 165cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey 27,5 6061 Aluminum Triple Butted 2021, Tapered head tube, Thru axle 12x148mm Boost, Post Mount Disc Mount, 31,6 Seat Post, Internal Cable Routing, Removable hanger, ISCG 05.
Suspension Fork
Marzocchi Bomber Z2 120 QR15x110
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS Shadow Plus
Shift Levers
Shimano Deore M6100
Cassette
Sun Race 11-51t 12-Speed
Crank
OC1 Alloy forged Boost 32t
Chain
KMC X12
Chain Guide
Orbea OC chainguide
Pedals
VP-229 Black with reflectors
Wheels
Rims
Mach1 Klixx 23c Tubeless Ready
Tires
Schwalbe Nobby Nic Perf, 27.5x2.35 TwinSkin TLR
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
Race Face Ride
Handlebar
Alloy Flat 31.8mm 720mm
Headset
FSA 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Royal Vivo
Seatpost
OC MC20 Mountain Control Dropper, 31,6mm, 100mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 20" | 24" | 27cm |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.48 mm |
| Bottom Bracket Height | 248 mm | 288 mm | 315 mm |
| Front Center | 555 mm | 627 mm | 681 mm |
| Rake | 40 mm | 40 mm | 44 mm |
| Trail | 114 mm | 114 mm | 114 mm |
| Stack | 440 mm | 513 mm | 567 mm |
| Reach | 315 mm | 359 mm | 382 mm |
| Top Tube Length | 443 mm | 508 mm | 536 mm |
| Seat Tube Angle | 74 ° | 74 ° | 75 ° |
| Seat Tube Length | 257 mm | 300 mm | 343 mm |
| Head Tube Angle | 66 ° | 66 ° | 65.5 ° |
| Head Tube Length | 90 mm | 100 mm | 95 mm |
| Chainstay Length | 343 mm | 388 mm | 418 mm |
| Wheelbase | 897 mm | 1012 mm | 1095 mm |
| Bottom Bracket Drop | 23 mm | 35 mm | 43 mm |
| Standover Height | 498 mm | 586 mm | 629 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 110 cm | 125 cm | 140 cm |
| Rider Max Height | 135 cm | 150 cm | 165 cm |
Model Overview
LAUFEY 27 H10 belongs to the Orbea Laufey model. Orbea launched 26 bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
The most economical model, the Orbea LAUFEY 20 H30 2022 has a starting price of 678$. Orbea LAUFEY H-LTD 2022 on the other hand is the most expensive at 2441$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2022 for 1592$. In conclusion, this bike price is 73.49% lower than the price of the average Trail bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
This bike has the Marzocchi Bomber Z2 fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When leaving the production line, the LAUFEY 27 H10 model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea LAUFEY 27 H10 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Orbea LAUFEY 27 H10 bike has 3 sizes, in the range of 110 cm – 165 cm (3.61 ft – 5.41 ft). In short, you can easily find one that suits you.
Dropper post
The Orbea model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
