Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Fork Fox Factory Float 34
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey Hydro 2018 Triple Butted 29/27.5+ design. Boost 12x148 ISCG 05
Suspension Fork
Fox 34 Float Factory 130 FIT4 3-Pos-Adj QR15x110 Kashima
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle
Cassette
SRAM GX XG-1275 Eagle 10-50t 12-Speed
Crank
SRAM Descendant CNC Eagle Dub Boost 32t Rotor QX1 DM SRAM 32t Chainring (EXTRA)
Chain
SRAM GX Eagle 12-Speed
Chain Guide
OneUp Components ISCG05 Guide
Pedals
N/A
Wheels
Rims
DT M-1900 Spline 35c TLR 15/110mm CL
Tires
Maxxis Rekon 2.8" 60 TPI Exo TLR
Brakes
Brakes
Shimano MT501 BR500 Hydraulic Disc Shimano XT M8000 Hydraulic Disc
Cockpit
Stem
Race Face Aeffect 35mm interface
Handlebar
Race Face Aeffect 35 20mm Riser 760mm Race Face Next 35 Riser 20/780mm+Turbine 35 Kit (B
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Italia XR Trail Selle Italia X-LR Ti Flow
Seatpost
Race Face Aeffect Dropper 31.6x385/125mm Crank brothers Highline 31,6x425/150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | MD | 18" | 20" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.53 mm | 1.48 mm | 1.43 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 680 mm | 698 mm | 732 mm | 760 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 95 mm | 106 mm | 95 mm | 95 mm |
| Stack | 618.9 mm | 623.5 mm | 632.7 mm | 646.5 mm |
| Reach | 381.6 mm | 408.2 mm | 428 mm | 450.6 mm |
| Top Tube Length | 568 mm | 597 mm | 619 mm | 645 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm | 520 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 130 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1101 mm | 1119 mm | 1153 mm | 1181 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 27" | 27" | 27" | 27" |
Model Overview
LAUFEY 27+ H-LTD completes the Orbea Laufey model. Orbea released 26 bikes variations of this model so far. Take a sneak peek at all Orbea Laufey bikes models from 2018, by clicking here.
Model range prices
Orbea LAUFEY 27+ H30 2018 is the most affordable bike of this model and has a price of 1499$. On the other hand, Orbea LAUFEY 27+ H-LTD 2018, is the most expensive and costs 3199$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Orbea released this model in 2018, its price was 3199$. If we compare this with the average Trail bike cost we notice that the price is 15.82% more expensive.
LAUFEY 27+ H-LTD components
Fork
The fork installed on this bike is the Fox Factory Float 34 model. The travel on this model is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the LAUFEY 27+ H-LTD bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Dropper post
Orbea LAUFEY 27+ H-LTD comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
