Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Fork RockShox Recon Silver RL
-
Groupset SLX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey Hydro 2018 Triple Butted 29/27.5+ design. Boost 12x148 ISCG 05
Suspension Fork
RockShox Recon RL 130 Air Q15x110 Boost
Drivetrain
Rear Derailleur
Shimano SLX M7000 GS Shadow Plus Direct Mount
Shift Levers
Shimano SLX M7000
Cassette
Sun Race 11-46t 11-Speed
Crank
OC-Custom PWl Charm-TT-Boost 32t
Chain
Shimano HG 601
Pedals
N/A
Wheels
Rims
Sun Ringle Duroc 40 Tubeless Ready
Tires
Maxxis Rekon 2.8" 60 TPI Exo TLR
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
Orbea OC-II
Handlebar
Orbea OC-II Riser 760mm
Headset
FSA 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Royal Custom Trail II 2043 HRN
Seatpost
Orbea Digit 31.6x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | MD | 18" | 20" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.53 mm | 1.48 mm | 1.43 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 680 mm | 698 mm | 732 mm | 760 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 95 mm | 106 mm | 95 mm | 95 mm |
| Stack | 618.9 mm | 623.5 mm | 632.7 mm | 646.5 mm |
| Reach | 381.6 mm | 408.2 mm | 428 mm | 450.6 mm |
| Top Tube Length | 568 mm | 597 mm | 619 mm | 645 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm | 520 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 130 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1101 mm | 1119 mm | 1153 mm | 1181 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 27" | 27" | 27" | 27" |
About this model
LAUFEY 27+ H30 is part of the Orbea Laufey model. There are 26 bikes that carry this model name. Take a sneak peek at all Orbea Laufey bikes models from 2019, by clicking here.
Model range prices
Orbea LAUFEY 27+ H30 2019 is the most affordable bike of this model and has a price of 1499$. On the other hand, Orbea LAUFEY 27+ H-LTD 2019, is the most expensive and costs 3199$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2019 for 1499$. Comparing this to the average Trail bike price, we see that the price is 84.26% lower.
LAUFEY 27+ H30 components
Fork
The LAUFEY 27+ H30 comes factory-installed with the RockShox Recon Silver RL fork. This has a travel range of 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on LAUFEY 27+ H30 are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The LAUFEY 27+ H30 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
