Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork Fox Performance Float 34
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 165cm
MD
160cm - 175cm
LG
170cm - 185cm
XL
180cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey Hydro Triple Butted 29" Boost 12x148 ISCG 05
Suspension Fork
Fox 34 Float Performance 140 3-Position QR15x110
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS Shadow Plus
Shift Levers
Shimano SLX M7100 I-Spec EV
Cassette
Shimano CS-M7100 10-51t 12-Speed
Crank
Race Face Aeffect 32t
Chain
Shimano M7100
Wheels
Rims
Race Face AR 30c Tubeless Ready
Tires
Maxxis Dissector 2.60" 60 TPI Exo TLR
Brakes
Brakes
Shimano M6120 Hydraulic Disc
Cockpit
Stem
OC Mountain Control MC20, 0º
Handlebar
OC Mountain Control MC20 Alu SL, Rise20, Width 800
Grips
Ergon GE10
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
ERGON SM Enduro
Seatpost
OC Mountain Control MC21, 31.6mm, Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.482 mm | 1.424 mm | 1.38 mm | 1.329 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 749 mm | 778 mm | 808 mm | 837 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 130 mm | 130 mm | 130 mm | 130 mm |
| Stack | 633 mm | 642 mm | 655.5 mm | 664.5 mm |
| Reach | 427 mm | 451 mm | 475 mm | 500 mm |
| Top Tube Length | 572 mm | 598 mm | 625 mm | 652 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 380 mm | 415 mm | 430 mm | 460 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 95 mm | 105 mm | 120 mm | 130 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1181 mm | 1210 mm | 1240 mm | 1269 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 770 mm | 770 mm | 770 mm | 770 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 160 cm | 170 cm | 180 cm |
| Rider Max Height | 165 cm | 175 cm | 185 cm | 198 cm |
About this model
LAUFEY H-LTD is an Orbea Laufey model. 29 bikes variations carry this model name so far. Take a sneak peek at all Orbea Laufey bikes models from 2024, by clicking here.
Model range prices
Orbea LAUFEY H30 2024 is the most affordable bike of this model and has a price of 1587$. On the other hand, Orbea LAUFEY H-LTD 2024, is the most expensive and costs 2646$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2646$. If we compare this with the average Trail bike cost we notice that the price is 4.38% smaller.
Overview of components
Fork
The fork installed on this bike is the Fox Performance Float 34 model. The travel on this model is 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the LAUFEY H-LTD model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The LAUFEY H-LTD has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 150 cm – 198 cm (4.92 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Orbea LAUFEY H-LTD includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
