Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 140mm -
Fork Marzocchi Bomber Z2
-
Groupset SLX, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 165cm
MD
160cm - 175cm
LG
170cm - 185cm
XL
180cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey Hydro Triple Butted 29" Boost 12x148 ISCG 05
Suspension Fork
Marzocchi Bomber Z2 140 QR15x110
Drivetrain
Rear Derailleur
Shimano SLX M7100 SGS Shadow Plus
Shift Levers
Shimano Deore M6100 I-Spec EV
Cassette
Shimano CS-M6100 10-51t 12-Speed
Crank
Shimano MT511 32t
Chain
Shimano M6100
Wheels
Rims
Orbea OC1 29c Tubeless Ready
Tires
Maxxis Rekon 2.60" FB 60 TPI Dual Exo TR
Brakes
Brakes
Shimano M6100 Hydraulic Disc
Cockpit
Stem
OC1 3D Forged 35mm interface 7º
Handlebar
OC1 35mm 12mm Rise 780mm
Headset
FSA 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Fortune QF-3091
Seatpost
OC MC20 Mountain Control Dropper, 31,6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.46 mm | 1.41 mm | 1.37 mm |
| Bottom Bracket Height | 313.5 mm | 313.5 mm | 313.5 mm | 313.5 mm |
| Front Center | 719 mm | 747 mm | 775 mm | 808 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 122 mm | 122 mm | 122 mm | 122 mm |
| Stack | 630 mm | 634 mm | 643 mm | 662 mm |
| Reach | 407 mm | 433 mm | 457 mm | 482 mm |
| Top Tube Length | 576 mm | 604 mm | 630 mm | 660 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm | 521 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1144 mm | 1172 mm | 1200 mm | 1233 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 676 mm | 712 mm | 724 mm | 761 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 160 cm | 170 cm | 180 cm |
| Rider Max Height | 165 cm | 175 cm | 185 cm | 198 cm |
Model Overview
LAUFEY H10 is an Orbea Laufey model. There are 26 bikes that carry this model name. You can easily view all of the Orbea Laufey bikes models from 2022, here.
Model range prices
The most economical model, the Orbea LAUFEY 20 H30 2022 has a starting price of 678$. Orbea LAUFEY H-LTD 2022 on the other hand is the most expensive at 2441$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2016$. Comparing this to the average Trail bike price, we see that the price is 37% lower.
Overview of components
Fork
This bike has the Marzocchi Bomber Z2 fork installed. The fork’s travel is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the LAUFEY H10 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea LAUFEY H10 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
LAUFEY H10 comes in 4 sizes, that range from 150 cm – 198 cm (4.92 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Orbea LAUFEY H10 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
