Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 140mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 165cm
MD
160cm - 175cm
LG
170cm - 185cm
XL
180cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey Hydro Triple Butted 29" Boost 12x148 ISCG 05
Suspension Fork
RockShox Recon RL Crown adjust Q15X110 Boost Solo Air 140mm
Drivetrain
Rear Derailleur
Shimano Deore M5100 SGS Shadow Plus
Shift Levers
Shimano Deore M5100
Cassette
Sun Race 11-51t 11-Speed
Crank
OC1 Alloy forged Boost 32t
Chain
KMC X11
Wheels
Rims
Orbea OC1 29c Tubeless Ready
Tires
Maxxis Rekon 2.60" FB 60 TPI Dual Exo TR
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
OC1 3D Forged 35mm interface 7º
Handlebar
OC1 35mm 12mm Rise 780mm
Headset
FSA 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Fortune QF-3091
Seatpost
OC MC20 Mountain Control Dropper, 31,6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.46 mm | 1.41 mm | 1.37 mm |
| Bottom Bracket Height | 313.5 mm | 313.5 mm | 313.5 mm | 313.5 mm |
| Front Center | 719 mm | 747 mm | 775 mm | 808 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 122 mm | 122 mm | 122 mm | 122 mm |
| Stack | 630 mm | 634 mm | 643 mm | 662 mm |
| Reach | 407 mm | 433 mm | 457 mm | 482 mm |
| Top Tube Length | 576 mm | 604 mm | 630 mm | 660 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm | 521 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1144 mm | 1172 mm | 1200 mm | 1233 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 676 mm | 712 mm | 724 mm | 761 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 160 cm | 170 cm | 180 cm |
| Rider Max Height | 165 cm | 175 cm | 185 cm | 198 cm |
About this model
LAUFEY H30 completes the Orbea Laufey model. 26 bikes variations carry this model name so far. Take a sneak peek at all Orbea Laufey bikes models from 2022, by clicking here.
Model range prices
Orbea LAUFEY 20 H30 2022 is the most affordable bike of this model and has a price of 678$. On the other hand, Orbea LAUFEY H-LTD 2022, is the most expensive and costs 2441$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Orbea LAUFEY H30 price was 1592$. If we compare this with the average Trail bike cost we notice that the price is 73.49% lower.
Overview of components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the LAUFEY H30 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea LAUFEY H30 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
LAUFEY H30 comes in 4 sizes, that range from 150 cm – 198 cm (4.92 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Orbea LAUFEY H30 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
