Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 165cm
MD
160cm - 175cm
LG
170cm - 185cm
XL
180cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey Hydro Triple Butted 29" Boost 12x148 ISCG 05
Suspension Fork
RockShox Recon RL Q15X110 Boost Solo Air 140mm
Drivetrain
Rear Derailleur
Shimano Deore M5100 SGS Shadow Plus
Shift Levers
Shimano Deore M5100
Cassette
Sun Race 11-51t 11-Speed
Crank
Forged alloy, 32t, Boost
Chain
KMC X11
Wheels
Rims
Alloy, Tubeless, 29", 29c, 32H
Tires
Maxxis Dissector 2.60" 60 TPI Exo TLR
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
Alloy 3D forged, 35mm interface, -7º
Handlebar
OC Mountain Control MC30, Rise20, Width 800
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Royal 2058 DRN
Seatpost
OC Mountain Control MC20, 31.6mm, Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.46 mm | 1.41 mm | 1.37 mm |
| Bottom Bracket Height | 313.5 mm | 313.5 mm | 313.5 mm | 313.5 mm |
| Front Center | 719 mm | 747 mm | 775 mm | 808 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 122 mm | 122 mm | 122 mm | 122 mm |
| Stack | 630 mm | 634 mm | 643 mm | 662 mm |
| Reach | 407 mm | 433 mm | 457 mm | 482 mm |
| Top Tube Length | 576 mm | 604 mm | 630 mm | 660 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm | 521 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1144 mm | 1172 mm | 1200 mm | 1233 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 676 mm | 712 mm | 724 mm | 761 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 160 cm | 170 cm | 180 cm |
| Rider Max Height | 165 cm | 175 cm | 185 cm | 198 cm |
Model Overview
LAUFEY H30 completes the Orbea Laufey model. There are 26 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Orbea LAUFEY H30 2023 is the most economical model, with a starting price of 1999$. Orbea LAUFEY H-LTD 2023 on the other hand costs 2999$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Orbea released this model in 2023, its price was 1999$. If we compare this with the average Trail bike cost we notice that the price is 38.17% smaller.
Overview of components
Fork
Orbea LAUFEY H30 2023 bike is equipped with the RockShox Recon Silver RL fork, and has 140mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The LAUFEY H30 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The LAUFEY H30 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Orbea LAUFEY H30 bike has 4 sizes, in the range of 150 cm – 198 cm (4.92 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the LAUFEY H30. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
