Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 20" -
Travel Front 40mm -
Fork Suntour
-
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Rim
Sizing
Recommended size guide.
12"
80cm - 105cm
16"
95cm - 120cm
20"
110cm - 135cm
24"
125cm - 150cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX 20 6061 Aluminum 2021, 135x9 QR, V-Brake + IS Disc Mount, 27,2 Seat Post, Internal Cable Routing, Central kickstand compatible, removable hanger, Fender and Carrier ready.
Suspension Fork
SR Suntour M3010 40mm V-Brake QR
Drivetrain
Rear Derailleur
Shimano Altus M310
Shift Levers
Shimano SL-M315
Cassette
Shimano TZ31 14-34t 7-Speed
Crank
Extra light 36t, 127mm, w/Chainguard
Chain
KMC Z7 GYBR
Pedals
VP-229 Black with reflectors
Wheels
Rims
Orbea Alloy 20"
Tires
Kenda Booster K1277 20x2.20" 30TPI
Brakes
Brakes
Junior alloy V-brake
Brake Levers
Junior V brake lever, alloy body and alloy lever, with reach adjustment
Cockpit
Handlebar
Orbea Alu integrated cockpit 540mm
Headset
VP-Z104PD 1-1/8" Semi-Cartridge
Seat
Saddle
DDK D2005 237x141mm
Seatpost
Digit Alloy 27.2x250mm Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 12" | 16" | 20" | 24" |
|---|---|---|---|---|
| Rake | 15 mm | 25 mm | 40 mm | 40 mm |
| Top Tube Length | 317 mm | 388 mm | 452 mm | 517 mm |
| Seat Tube Angle | 70 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 130 mm | 205 mm | 257 mm | 300 mm |
| Head Tube Angle | 70 ° | 68 ° | 69 ° | 69 ° |
| Head Tube Length | 80 mm | 90 mm | 100 mm | 100 mm |
| Chainstay Length | 232 mm | 297 mm | 347 mm | 392 mm |
| Wheelbase | 563 mm | 736 mm | 865 mm | 977 mm |
| Wheels | 20" | 20" | 20" | 20" |
| Rider Min Height | 80 cm | 95 cm | 110 cm | 125 cm |
| Rider Max Height | 105 cm | 120 cm | 135 cm | 150 cm |
About this model
MX 20 XC belongs to the Orbea Mx model. 76 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Orbea MX 16 2022 is the most affordable bike of this model and has a price of 424$. On the other hand, Orbea MX 20 27.5 2022, is the most expensive and costs 996$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Mountain bikes
If you want an acceptable Mountain bike you should know that the average price is 616$. However, even though the average price of a Mountain bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 487$. If we compare this with the average Mountain bike cost we notice that the price is 26.49% smaller.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
MX 20 XC components
Fork
Orbea MX 20 XC 2022 bike is equipped with the Suntour fork, and has 40mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the MX 20 XC bike is equipped with the 20″ aluminum model. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The MX 20 XC comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
This bike is available in 4 sizes. They vary from 80 cm – 150 cm (2.62 ft – 4.92 ft). In conclusion, finding one for you shouldn’t be a problem.
