Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 24" -
Groupset Altus, Shimano -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Rim
Sizing
Recommended size guide.
12"
80cm - 105cm
16"
95cm - 120cm
20"
110cm - 135cm
24"
125cm - 150cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX 24 6061 Aluminum 2021, 135x9 QR, V-Brake + IS Disc Mount, 27,2 Seat Post, Internal Cable Routing, Central kickstand compatible, removable hanger, Fender and Carrier ready.
Suspension Fork
Orbea MX 24 Hi Ten 2021, 100x9 QR, V-Brake, Mini + Long Fender ready
Drivetrain
Rear Derailleur
Shimano Altus M310
Shift Levers
Shimano SL-M315
Cassette
Shimano TZ31 14-34t 7-Speed
Crank
Extra light 36t, 152mm, w/Chainguard
Chain
KMC Z7 GYBR
Pedals
VP-229 Black with reflectors
Wheels
Rims
Orbea Alloy 24"
Tires
Kenda 841 24x1.75 reflective tape
Brakes
Brakes
Junior alloy V-brake
Brake Levers
Junior V brake lever, alloy body and alloy lever, with reach adjustment
Cockpit
Handlebar
Orbea Alu integrated cockpit 540mm
Headset
VP-Z104PD 1-1/8" Semi-Cartridge
Seat
Saddle
DDK D2405 256x138mm
Seatpost
Digit Alloy 27.2x300 mm Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 12" | 16" | 20" | 24" |
|---|---|---|---|---|
| Rake | 15 mm | 25 mm | 40 mm | 40 mm |
| Top Tube Length | 317 mm | 388 mm | 452 mm | 517 mm |
| Seat Tube Angle | 70 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 130 mm | 205 mm | 257 mm | 300 mm |
| Head Tube Angle | 70 ° | 68 ° | 69 ° | 69 ° |
| Head Tube Length | 80 mm | 90 mm | 100 mm | 100 mm |
| Chainstay Length | 232 mm | 297 mm | 347 mm | 392 mm |
| Wheelbase | 563 mm | 736 mm | 865 mm | 977 mm |
| Wheels | 24" | 24" | 24" | 24" |
| Rider Min Height | 80 cm | 95 cm | 110 cm | 125 cm |
| Rider Max Height | 105 cm | 120 cm | 135 cm | 150 cm |
About this model
MX 24 PARK is part of the Orbea Mx model. There are 76 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Orbea MX 16 2022 is the most affordable bike of this model and has a price of 424$. On the other hand, Orbea MX 20 27.5 2022, is the most expensive and costs 996$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Mountain bikes average price
According to our math, the average price for a trustworthy Mountain bike is 616$. However, even though the average price of a Mountain bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 572$. Comparing this to the average Mountain bike price, we see that the price is 7.69% smaller.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
When leaving the production line, the MX 24 PARK model has 24″ aluminum wheels. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea MX 24 PARK is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 80 cm – 150 cm (2.62 ft – 4.92 ft). In conclusion, it won’t take much to find one that’s right for you.
