Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 24" -
Groupset Altus -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
16"
100cm - 116cm
20"
114cm - 136cm
24"
134cm - 156cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX 24 Alu
Suspension Fork
Orbea Alu 24"
Drivetrain
Rear Derailleur
Shimano Altus M2000 SGS Shadow
Cassette
Shimano HG200 11-36 9-Speed
Chain
Shimano HG53 9-Speed
Pedals
Resine BMX
Wheels
Rims
Orbea Alu 24"
Brakes
Brake Levers
Orbea
Cockpit
Stem
Orbea OC-II
Handlebar
Orbea OC-I Riser 560mm
Headset
1-1/8" Semi-Integrated
Seat
Saddle
Velo 5061
Seatpost
Orbea OC-I 27.2x300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 20" | 24" | 26" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.12 mm | 1.33 mm | 1.42 mm | 1.46 mm |
| Bottom Bracket Height | 192 mm | 237 mm | 272 mm | 280 mm |
| Front Center | 433 mm | 488 mm | 554 mm | 594 mm |
| Rake | 35 mm | 33 mm | 36 mm | 39 mm |
| Stack | 317 mm | 419 mm | 494 mm | 532 mm |
| Reach | 282 mm | 314 mm | 347 mm | 365 mm |
| Top Tube Length | 379.3 mm | 439 mm | 513 mm | 530 mm |
| Seat Tube Angle | 73.2 ° | 73 ° | 72 ° | 73 ° |
| Seat Tube Length | 207 mm | 257 mm | 329 mm | 367 mm |
| Head Tube Angle | 71 ° | 72 ° | 71 ° | 70 ° |
| Head Tube Length | 90 mm | 95 mm | 90 mm | 90 mm |
| Chainstay Length | 305 mm | 337 mm | 381 mm | 419 mm |
| Wheelbase | 738 mm | 824 mm | 933 mm | 1009 mm |
| Bottom Bracket Drop | 8 mm | 16 mm | 30 mm | 45 mm |
| Standover Height | 436 mm | 527 mm | 654 mm | 707 mm |
| Wheels | 24" | 24" | 24" | 24" |
| Rider Min Height | 100 cm | 114 cm | 134 cm | 154 cm |
| Rider Max Height | 116 cm | 136 cm | 156 cm | cm |
Model Overview
MX 24 TEAM-USA belongs to the Orbea Mx model. There are 76 frames that carry this model name. Take a sneak peek at all Orbea Mx frames models from 2018, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Mountain frames
Our math shows that the average cost of a dependable Mountain frame is 514$. However, you could also get a good Mountain frame even if you pay a lower amount than the average price. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
This frame was released in 2018 and its price was 499$. In conclusion, this frame price is 3.01% lower than the price of the average Mountain frame.
Overview of components
Fork material
When it comes to the fork, this frame has an aluminum one, so there won’t be much extra weight added to the frame. However, they are not so stiff as carbon forks are.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The MX 24 TEAM-USA comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
